General information

Service parts
indentification

Nameplate

4
H1B 160 cc Bent Axis Motor
The following information and procedure is used to identify the module group, item number,
manufacture date, part number, and part name of the parts included in the H1B 160 cc variable
displacement motors.
The parts listed include all parts which may be used when performing either "Minor Repairs", "Major
Repairs" or "Conversions" on the H1B 160 cc motor.
Each unit will have a nameplate affixed to the
end cap. The nameplate will include the following
information.
Model Code
The Danfoss model code completely defines the
specific unit and must be used when ordering parts
to service this product.
Model Number
The Danfoss model number is used by the factory in
manufacturing. On repeat orders, a complete unit
can be ordered by the model number.
Serial Number
The Danfoss serial number is used to identify the
manufacture date and the unit sequence in the
build. The serial number is also used to identify the
units warranty time period.
The letter code indicates the location of original
manufacture (assembly). "N" indicates the unit was
originally assembled in Neumuenster, Germany.
"H" indicates the unit was originally assembled in
Haiyan, China.
The first number (2 digits) indicates the year of
manufacture. ("11" would indicate the unit was
manufactured in 2011)
The second number (2 digits) indicates the calendar
week of manufacture.
The third number (5 digits) is a sequential number
used to identify a specific unit.
AX00000226 | L1119730 • Rev 0400 • March 2016
83013646
Model No./Ident No.
H1B160-A-A-L1-BA-N-
Model Code
B-PA-CN-KN-N-N-NN-
NN-032-N-00-NNN
N-11-20-23456
Serial No.
Made in Germany
