General information

Date code

Service bulletins

Procedure to identify a part

H1B 160 cc Bent Axis Motor
The date code is defined as the year and week of manufacture. The same item number may list more
than one part number. This indicates that there is more than one configuration for that item number.
You will see that there are different date codes for the different part numbers. Find the date code of
your unit from the nameplate to determine which service part number you need to order.
EXAMPLE: The service part desired is Item G30
Order Date Date
Code Item Begin End
80 G30 89-17
G30 87-02 89-16
All units using this order code with a date code of 87-02 and up to and including 89-16, must use part
number "8000151". All units with a date code of 89-17 and newer must use part number "8000243. " .
A Service Bulletin Number (SB-_ _ _ _ - _ _ _) may follow the "Part Name" of the part you desire. You
must read that Service Bulletin prior to ordering that part. The information contained in these Service
Bulletins, as of the print date of this bulletin, are included at the end of this manual. Service Bulletins
contain more detailed information such as interchangeability, what additional parts are involved, etc.
It is suggested that you add additional Service Bulletins to this manual as you recieve them.
General
The modular design of H1B units results in a simplified service parts list and part number identification
procedure.
The same item numbers are used for same part names on all units within a product type. (Example:
The lip seal - Item G0020 has the same item number on all motors.)
A part number that has another number following it in parentheses is done to make this a world wide
manual. The first number is sold in Germany. The number in parentheses is sold in the United States.
(Example: 314583 (9008000-0118), customers would order 9008000-0118 if ordering the part in the
United States.)
Example of a Part Identification
The nameplate on an H1 motor has an Order Code of H1B160 A L1 BA N B PA CN KN N N NN NN 032 N
00 NNN. Use the following procedures to determine the part number of the minimum angle set screw
used on this motor.
1) Referring to the minimum displacement module in the Order Code (see page 7), the minimum
angle set screw option for this motor is identified by the code "032". (H1B160 A L1 BA N B PA CN KN N N
NN NN 032 N 00 NNN)
2) Referring to the Service Parts List, find the minimum displacement group. Next find the order code
that relates to this unit, which is "032". The minimum angle set screw is found to be item N1000 and
part number 750646.
AX00000226 | L1119730 • Rev 0400 • March 2016
Part Number Part Name
8000243 End cap gasket
8000151 End cap gasket (SB-1995-006)
Usage
1
1
5
