Danfoss H1B 160 cc Parts Manual page 77

Parts Manual
Shaft
Shaft
Order Date
Code Item Begin
DN QH030 11-18
QH300 11-18
DS H0180 11-18
QH030 11-18
QH300 11-18
EN QH030 11-18
QH300 11-18
ES H0180 11-18
QH030 11-18
QH300 11-18
FN QH030 11-18
QH300 11-18
FS H0180 11-18
QH030 11-18
QH300 11-18
KN QH030 11-18
QH300 11-18
KS H0180 11-18
QH030 11-18
QH300 11-18
LN QH030 11-18
QH300 11-18
LS H0180 11-18
QH030 11-18
QH300 11-18
PS H0180 11-18
QH030 11-18
QH300 11-18
H1B 160 cc Bent Axis Motor
Date
End Part Number
11100638
11088312
11054505
11100638
11088315
11100638
11054445
11054505
11100638
11054407
11100638
11054488
11054505
11100638
11054424
11100638
11054483
11054505
11100638
11054411
11100638
11054491
11054505
11100638
11054427
11054505
11100638
11096984
AX00000226 | L1119730 • Rev 0400 • March 2016
Part Name
Piston ring kit
Shaft assembly, 27 tooth, 16/32 pitch
Speed ring
Piston ring kit
Shaft assembly, 27 tooth, 16/32 pitch, speed ring
Piston ring kit
Shaft assembly, 13 tooth, 8/12 pitch
Speed ring
Piston ring kit
Shaft assembly, 13 tooth, 8/12 pitch, speed ring
Piston ring kit
Shaft assembly, 15 tooth
Speed ring
Piston ring kit
Shaft assembly, 15 tooth, speed ring
Piston ring kit
Shaft assembly, 21 tooth, DIN
Speed ring
Piston ring kit
Shaft assembly, 21 tooth, DIN, speed ring
Piston ring kit
Shaft assembly, 24 tooth, DIN
Speed ring
Piston ring kit
Shaft assembly, 24 tooth, DIN, speed ring
Speed ring
Piston ring kit
Shaft assembly, 27 tooth, 16/32 pitch, speed ring
Qty. per
Model/Kit
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
77
