Comtech EF Data cdm-570a Revision page 4


Ethernet IP Address – Use the 'Configuration | LAN' page to view the IP Address/Mask, as
shown in this example:
Using the CDM‐570A/L Serial Remote Interface (via the User PC / terminal emulator
program):

Firmware Info – Use the <0/SWR? (condensed) or <0/FRW? (detailed) remote query.

Ethernet Traffic IP Address – Use the <0/IPA? remote query.
2) Next, create a temporary folder (subdirectory) on the User PC for the firmware archive download.

Drive letter "c:" is used in these examples. Any valid, writable drive letter can be
used.

Typical for all tasks: Type the command without quotes, and then press Enter to
execute.
There are several ways to create a temporary folder on a Windows‐based PC:
A. Use the Windows Desktop to create and rename the temporary folder.

Right‐click anywhere on the desktop to open the popup submenu, and then select New >
Folder to create a temporary folder on the desktop.

Right‐click on the new folder and then select "Rename" from the popup submenu. Rename
this folder to "temp" or some other convenient, unused name.
Re‐Flashing Your CDM‐570A/570AL Satellite Modem 4 FLG‐CDM570A Revision 1
