On the CDM‐570A HTTP Interface 'Admin | Firmware | Packet Processor' page, use the
'Upgrade To' drop‐down list to select Latest, Image 1, or Image 2.

Click [Submit] to save.
You may proceed once you have specified the file transfer destination slot.
4) Use Command‐line to initiate the FTP session with the modem.
A. Type "ftp xxx.xxx.xxx.xxx" (where 'xxx.xxx.xxx.xxx' is the CDM‐570A/L Ethernet
Traffic/Management IP Address).
B. Enter the Admin User Name and Password to complete login.
C. Type "bin" to set the binary transfer mode.
D. Type "prompt", and then type "hash" to facilitate the file upload.
E. Type "put FW‐0020781*_CDM‐570A_PaP_#_#_#.bin" to begin the file upload. It will take
several minutes to transfer and write the files to flash memory. Once the file transfers,
Command‐line displays the upload result, similar to:
200 Port OK
150 Opening data connection
226 Packet Processor upgrade complete – Safe to reboot.
ftp: XXXXXXXX bytes sent in X.XXSeconds XXXX.XXKbytes/sec.
F. Once the FTP upload is complete, as the upgrade process continues, the modem front panel
displays:
G. The process sequences through several blocks – this will take several minutes. Once the update
process is complete, the modem front panel displays:
Press the modem front panel CLEAR key as prompted.
H. Type "bye" to terminate the FTP session, and then close the Command‐line window.
5) Use the modem front panel menus or the CDM‐570A HTTP Interface 'Admin | Firmware | Packet
Processor' page to verify that the PC‐to‐Modem IP Packet Processor firmware FTP file transfer was
successful.
6) Use the modem front panel menus and/or the CDM‐570A HTTP Interface 'Admin | Firmware |
Modem' page and, as applicable, the 'Admin | Firmware | Packet Processor' page to select the
desired firmware images to boot from:
Re‐Flashing Your CDM‐570A/570AL Satellite Modem
IP OPTION CARD UPGRADING
..PLEASE WAIT
Upgrade finished
Press CLEAR to continue.
