Using the CDM‐570A/L Front Panel menus:

Base Modem Firmware Info – Use the SELECT: UTIL  Firmware  Info  Image#1 or
Image#2  Bulk menu branches, as shown in this example:

IP Packet Processor Firmware Info – Use the SELECT: UTIL  Firmware  Info  PaP
menu branches, as shown in this example:

Ethernet IP Address – Use the CONFIG: Rem  Ethernet  Address menu branch, as
shown in this example:
Using the CDM‐570A HTTP Interface (via the User PC Web Browser – this assumes that you
have already noted the Traffic/Management IP Address, which was previously required to
open the CDM‐570A HTTP Interface):

Base Modem Firmware Info – Use the 'Admin | Firmware | Modem' page, as shown in this
example:

IP Packet Processor Firmware Info – Use the 'Admin | Firmware | Packet Processor' page,
as shown in this example:
Re‐Flashing Your CDM‐570A/570AL Satellite Modem
Chapter 6. FRONT PANEL OPERATION
Chapter 7.5 HTTP (Web Server) INTERFACE
Chapter 8. SERIAL‐BASED REMOTE PRODUCT MANAGEMENT
Bulk#1:
FW-0020683*
PaP:
FW-0020781*
Ether IP Address/Range:
192.168.001.011/24 ◄ ►,▲▼
MM/DD/YY
#.#.#
MM/DD/YY
#.#.#
3 FLG‐CDM570A Revision 1
