A. Using the modem front panel menus:

First, to select the desired Boot Image, make sure that you are operating in LOCAL mode
(CONFIG: Remote  Local).

For the Base Modem firmware image, go to the SELECT: Utilities  Firmware  Select
menu branch and use the
the front panel ENTER key when done.
B. Using the CDM‐570A HTTP Interface:

For the Base Modem firmware, go to the 'Admin | Firmware | Modem' page. Use the 'Next
Reboot, will use' drop‐down list to select Latest, Image#1 or Image#2. Click [Submit] to
save.

For the IP Packet Processor firmware, go to the 'Admin | Firmware | Packet Processor'
page. Use the 'Boot From' drop‐down list to select Latest, Image#1 or Image#2. Click
[Submit] to save.
Reboot the CDM‐570A/L. You may perform a 'soft reboot' or a 'hard reboot' as follows:
7)

For a soft reboot, use the CDM‐570A HTTP Interface 'Admin| Reboot' page. Click [Reboot
Now]. Both the web page and the modem front panel will display messages similar to
"Rebooting, Please wait..." as reboot commences.

For a hard reboot, from CDM‐570A/L rear panel, turn off or otherwise disconnect, and then
turn on/reconnect the power source to execute reboot of the modem.
The system reboot is complete once the modem front panel displays the top‐level "splash"
screen:
You will need to log in to a new Web session at this time. The CDM‐570A HTTP Interface 'Home'
page will serve to verify that the new firmware version is active, as shown in this example:
The CDM‐570A/L is now operating with its latest firmware. The firmware update process is
now complete.
Re‐Flashing Your CDM‐570A/570AL Satellite Modem
▲▼
arrow keys to select the Next Reboot Image as 1 or 2. Press
Comtech CDM-570AL Modem
Firmware Version: #.#.#
