7.03 Display PCB3 Removal
WARNING
!
Read and follow safety information in Section 6.02 before proceeding with disassembly.
1. Remove Control Panel screws.
2. Disconnect the harness from the connectors.
3 Remove Display PCB3.
4. Remove Remote Interface PCB4.
Manual 0-5448
1
7-3
ESAB FABRICATOR 141i
A-12929
DISASSEMBLY PROCEDURE
