(3) Operator Display (Sn-03)

•Parameter code (Sn-03= 0 or 1)
Set the parameter Sn-03 as 0 or 1 to determine the access status as follows.
Sn-03
0
1
• Initialized setting of parameter (Sn-03= 7∼12)
Except the parameter of Sn-01∼02 and Sn-61, the parameter groups of An-□□,
Bn-□□, Cn-□□ and Sn-□□ can be initialized as factory setting according to
the different input voltage. At the same time, the terminal
wire or 3-wire operation mode under different setting of Sn-03. Please see 2-/3-
wire operation mode on page 81.

(4) Run Source Selection (Sn-04)

•The parameter is used to select the source of run command.
Sn-04 = 0 : digital operator
1 : control circuit terminal
2 : RS-485 communication
•If Sn-04 is set as 1, the run source is from the control circuit terminal. Under the
initial setting of 2-wire operation (through setting of Sn-03=7 or 9 or 11), the run
source will be FWD/STOP, REV/STOP.
•If Sn-04 is set as 1, the run source is from the control circuit terminal. Under the
initial setting of 3-wire operation (through setting of Sn-03=8 or 10 or 12), the run
source will be RUN, STOP, FWD/ REV.
•For more details, see "2-/3- wire operation" on page 81.

(5) Frequency Command Setting Method Selection (Sn-05)

•The parameter is used to select the source of frequency command.
Sn-05 = 0 : digital operator
1 : control circuit terminal
2 : RS-485 communication
(6) Stopping Method Selection
•Setting the stopping method used when a stop command is executed.
Setting
0
1
2
3
DRIVE mode
Set
An, Bn
An
Deceleration to stop
Coast to stop
DC braking stop: Stops faster than coast to stop, without regenerative
operation.
Coast to stop with timer: Run sources are disregarded during decel. time.
Read Only
Sn, Cn An, Bn, Sn, Cn
Bn, Sn, Cn
(Sn-06)
Function
72
PRGM mode
Set Read Only
－
An Bn, Sn, Cn
∼
can be set as 2-
