1.2 Installation

When installing the inverter, always provide the following space to allow normal
heat dissipation.
50 mm
min.
(a) Space in Side
CAUTION
Location of equipment is important to achieve proper performance and normal
operating life. The 7200MA-model unit should be installed in area where the
following conditions exist.
•Ambient temperature : -10
•Install 7200MA in a location free from rain, moisture and not in direct sunlight.
•Install 7200MA in a location free from harmful mist, gases, liquids, dusts and
metallic powder.
•Install 7200MA in a location without excessive oscillation and electromagnetic
noise.
•If more than 1 inverter are installed in a box, be sure to add a cooling fan or air
conditioner to maintain the air temperature below +45
50 mm min.
30 mm
30 mm
min.
min.
Fig. 1 Air clearance for 7200MA wall mounting
o
C∼+40
120 mm
min.
120 mm
min.
(b) Space in Top/bottom
o
C
4
AIR
ambient
temperature
-10 ~ + 40 ℃
AIR
o
C.
