2-B Standard Connection Diagram - TECO speecon 7200ma Instruction Manual

(B) For Standard Type
•JNTMBGBB□□□□JK－－1
•JNTMBGBB□□□□JKA－1
Main Ckt
Power Supply
FWD/STOP
REV/STOP
External Fault
Fault RESET
Multi-Step
Speed Ref.1
Multi-Step
Speed Red.2
Jogging
Acc. & Dec.
Switch
2kΩ, 1/2W
0 ~ +10V
2kΩ
1/2W
4 ~ 20 mA
0 ~ +10V
0V
EXTERNAL PG
DC VOLTAGE
PG INPUT
(A PHASE)
Shield
(*1)
Wire
(*2) The terminal arrangement
(*3) The control board code No. ： 3P101C0380003
220V : 3-20HP, 440V : 3-20HP
MC
NFB
R/L1
S/L2
T/L3
("Close":FWD)
1
FWD
2
REV ("Close":REV)
3
Eb
4
RESET
5
6
Multi-Function
7 Contact Input
8
SC
Digital signal Common
E
Shield Sheath
+15V Power Supply for
Speed Ref.
VIN Master Speed Ref. 0 ~ 10V, (20kΩ )
AIN Master Speed Ref.
P
P
AUX Multi-Funtion
Analog Input
P
GND Analog signal Common
(*1)
TP1
IP12
IG12
A(+)
A(-)
Shielded
P
Twisted Wire
SC
1
E
2
Fig. 2-b Standard connection diagram
•JNTMBGBB□□□□AZ－－1
•JNTMBGBB□□□□AZA－1
Braking Resistor
B1/P B2
Analog
Output 1
Analog
Output 2
(+15V, 20 mA)
4 ~ 20 mA, (250Ω)
0 ~ 10V, (20kΩ )
OPEN
IP12
PULL UP
3 5 7 VIN AIN AUX DO1 DO2 DOG IP12
4 6 8 GND GND AO1 AO2
+15V
10
U/T1
V/T2
IM
W/T3
E
Grounding Lead
(<100 Ω)
AO1
AO2
Analog Monitor 1, 2
(DC 0 ~ 10 V)
GND
RA
Multi-Function Contact Output
RB
250V AC, <1A
30V DC, <1A
RC
DO1
DO2
Multi-Function Output 1, 2
(Open Collector 48V, 50mA)
DOG
S(+)
RS-485 Port
S(-)
A(+) A(-)
E S(+) S(-) RA RB RC
IG12
