4.2 Error Message and Troubleshooting

(A) Protective Function
LCD Display
(English)
Fault
DC Volt. Low
Fault
Over Current
Fault
Ground Fault
Fault
Over Voltage
Fault
Over Heat
Fault
Motor Over Load
Fault
Inverter Over Load
Fault
Over Torque
Fault
Ext. Fault3
Fault
Ext. Fault5
Fault
Ext. Fault6
Fault
Ext. Fault7
Fault
Ext. Fault8
Fault
Inverter EEPROM EEPROM (BCC, no.) is bad.
Fault
Inverter A/D
Fault
PG Over Sp.
Fault
PG Open
Fault
Sp.Deviat Over
Fault
RS-485 Interrupt
The main circuit DC voltage becomes lower than the low voltage
detection level (Cn-34).
The inverter output current becomes approx. 200% and above the
inverter rated current.
A ground fault occurs at the inverter output side and the ground-fault
current exceeds approx. 50% of the inverter rated current.
The main circuit DC voltage becomes excessive because of
regeneration energy caused by motor decelerating.
The temperature of the cooling fin reaches the detection level.
Motor overload is detected by the electronic thermal relay.
(motor protection)
The electronic thermal sensor detects inverter overload while the
output current exceeds 112% of rated value. (inverter protection)
Over torque is detected while the output current is larger than or
equal to the setting of Cn-26. (machine protection)
External fault signal
External fault signal
External fault signal
External fault signal
External fault signal
EEPROM fault
A/D converter (inside the CPU) fault
Excessive PG speed fault
PG is open-circuit
Excessive speed deviation
MODBUS Communication fault occurs .The inverter remains
operating.
Fault Contents
105
Fault Contact
Output
Operation
Operation
Operation
Operation
Operation
Operation
Operation
Operation
Operation
Operation
Operation
Operation
Operation
operation
