EXPLODED VIEW AND PARTS LIST

Part# Stock #
1 2307-001
2 2307-002
3 2307-003
4 2307-004
5 2307-005
6 2307-006
7 2307-007
8 2307-008
9 2307-009
10 2307-010
11 2307-011
12 2307-012
13 2307-013
14 2307-014
15 2307-015
16 2307-016
17 2307-017
18 2307-018
19 2307-019
20 2307-020
21 2307-021
22 2307-022
Description
COLLET NUT
BRASS COLLET
BEARING 626zz
ROTOR
BEARING 698zz
STATOR
PREVENT SPRING
SPINDLE LOCK BUTTON
LOCKING SLEEVE
BRUSH
BRUSH SPRING
BRUSH BASE
BRUSH CAP
SCREW
RIGHT HOUSING
CIRCUIT BOARD
SWITCH
SCREW
PLACE BOARD
LEFT HOUSING
CORD SLEEVE
POWER CORD
