- Page 1 Cimarec Hot Plates ™ OPERATION MANUAL AND PARTS LIST Model # Top Plate Size Voltage HP130914 HP130915 HP130910-33 220-240 HP131224 HP131225 HP131220-33 220-240 HP131534 10x10 HP131535 10x10 HP131530-33 10x10 220-240 LT1312X1 • 10/28/09...
-
Page 2: Table Of Contents
Table of Contents Safety Information ..............................3 Warnings ..............................3 Specifications ..............................5 Heating Specifications ..........................6 Environmental Conditions ..........................7 Declaration of Conformity..........................7 Introduction................................8 General Usage ..............................8 Principles of Operation............................9 Unpacking and Installation ..........................10 Unpacking ..............................10 Installation ..............................10 Operation ................................11 Setting the Temperature ..........................11 To Achieve Fast Heat-Up of Large Volumes ....................11 Heating Small Volumes ..........................12 Heating Metal Vessels and Sand Baths......................12... -
Page 3: Safety Information
Safety Information Your Thermo Scientific Cimarec Hot Plate has been designed with function, reliability, and safety in mind. It is your responsibility to install it in conformance with local electrical codes. For safe operation, please pay Alert Signals attention to the alert signals throughout the manual. - Page 4 AFETY NFORMATION nents which may ignite such materials. Keep top surface clean. Use a non-abrasive cleaner. Alkali spills, hydrofluoric acid spills or phosphoric acid spills may damage top and lead to thermal failure. Unplug unit and remove spills promptly. Do not immerse unit for cleaning. Replace the top immediately if damaged by etching, scratching or chipping.
-
Page 5: Specifications
Specifications 4" X 4" Model Number HP130915 HP130910-33 HP130914 Overall Dimensions in. (cm) Width 5.0” (12.7 cm) 5.0” (12.7 cm) 5.0” (12.7 cm) Height 3.6" (9.7 cm) 3.6" (9.7 cm) 3.6" (9.7 cm) Depth 10.0" (25.4 cm) 10.0" (25.4 cm) 10.0"... -
Page 6: Heating Specifications
PECIFICATIONS Heating Specifications Top Plate Surface - Solid Ceramic Temperature range All 4" x 4" and 7" x 7" models: 41°F to 1004°F (5°C* - 540°C) All 10" x 10" models: 41°F to 752°F (5°C - 400°C) Heat-up time to maximum temperature (unloaded top plate). 8 minutes Temperature stability at the center of the top plate surface (@ 100°C). -
Page 7: Environmental Conditions
PECIFICATIONS Environmental Conditions Operating: 17°C to 27°C; 20% to 80% relative humidity, non-condensing. Installation category II (overvoltage) in accordance with IEC 664. Pollution degree 2 in accordance with IEC 664. Altitude Limit: 2,000 meters. Storage: -25°C to 65°C 10% to 85% relative humidity Declaration of Conformity (for 220-240 volt, -33 CE models only) We hereby declare under our sole responsibility that this product conforms with the technical requirements of... -
Page 8: Introduction
Introduction Please read all the information in this manual before operating the unit. Your Cimarec hot plate is a general purpose heating plate designed for laboratory procedures requiring precise con- trol of temperature. Each Cimarec hot plate model includes a digital display for monitoring actual tempera- ture. -
Page 9: Principles Of Operation
Principles of Operation Each Cimarec unit utilizes the latest in microprocessor technology to deliver a reliable, controlled, ceramic top hot plate. Your Cimarec hot plate has an electronic closed-loop feedback control which will accurately maintain temper- ature setpoints from 5°C through 400°C or 540°C, depending on the model. -
Page 10: Unpacking And Installation
Unpacking and Installation Unpacking Remove your Cimarec hot plate from the carton. Inspect to ensure that the unit has not been damaged during shipment. If the unit appears to have sustained shipping damage contact the distributor from whom you purchased this product or Customer Service at 800-553-0039. -
Page 11: Operation
Operation Warning When plugging in the hot plate and powering it up for the Use caution when heating volatile first time, you will see the software version and hertz dis- materials; top surface and element played briefly on the digital display. can reach the “Flash Point Temperature”... -
Page 12: Heating Small Volumes
PERATION Heating Small Volumes Note Preheating small volumes is not necessary as it may The solution temperature is approxi- cause the temperature to overshoot the desired set- mately 25% cooler than the hot plate point. surface temperature. Heating Metal Vessels and Sand Baths Note If you allow the top plate to reach the... -
Page 13: Maintenance
Maintenance General Cleaning Instructions Wipe exterior surfaces with lightly dampened cloth con- taining mild soap solution. -
Page 14: Troubleshooting
Troubleshooting Error Codes The following errors should not be addressed by the user. If any of the errors appear, contact Technical Service at 800-553-0039. Displayed Message Intended to Detect Cause Solution Thermocouple Thermocouple not connected. Replace element Call Tech. Service out of range. -
Page 15: Exploded Views
Exploded Views 220-240V Models Only Optional Accessory Ref. "A" 4x4 Exploded View... - Page 16 XPLODED IEWS (Note routing of leads and thermocouple) Number located this side. 4x4 Exploded View - Top Plate...
- Page 17 XPLODED IEWS Optional Accessory 220-240V Models Only Ref. "A" 7x7 Exploded View...
- Page 18 XPLODED IEWS (Note routing of leads and thermocouple) Number located this side. 7x7 Exploded View - Top Plate...
- Page 19 XPLODED IEWS Optional Accessory 220-240V Models Only Ref. "A" 10x10 Exploded View...
- Page 20 (Note routing of leads and thermocouple) Number located this side. 10x10 Exploded View - Top Plate...
-
Page 21: Wiring Diagram
Wiring Diagram... -
Page 22: Replacement Parts
Replacement Parts 4x4 Part No. 7x7 Part No. 10x10 Part No. Description 261575 261575 261575 PC Board Fuse - 220-240V FTX34 FTX34 FTX34 Foot (4) PC1312X1 PC1312X1 PC1315X1 Control Board - 100V, 120V PC1312X2 PC1312X2 PC1315X2 Control Board - 220-240V 266058 266058 266058... -
Page 23: Ordering Procedures
Ordering Procedures Please refer to the Specification Plate for the complete model number, serial number, and series number when requesting service, replacement parts or in any corre- spondence concerning this unit. All parts listed herein may be ordered from the Thermo Scientific dealer from whom you purchased this unit or can be obtained promptly from the factory. -
Page 24: Warranty
(ii) misuse (including use inconsistent with written operating instructions for the product), mishandling, contamination, overheating, modification or alteration of the product by any customer or third party or (iii) use of replacement parts that are obtained from a party who is not an authorized dealer of Thermo Scientific prod- ucts.
