Thermo Scientific SUPER-NUOVA 1359 Series Operation Manual And Parts List

Thermo Scientific SUPER-NUOVA 1359 Series Operation Manual And Parts List

Multi-place stirrer and stirring hot plates
Hide thumbs Also See for SUPER-NUOVA 1359 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Multi-Place Stirrer and
Stirring Hot Plates
LT1359X1 • 10/27/09
SUPER-NUOVA
OPERATION MANUAL
AND PARTS LIST
SERIES 1359 and 1360
Model #
S136030-33
S136035
SP135930-33
SP135935
Voltage
Description
220-240
120
220-240
Stirring Hot Plate
120
Stirring Hot Plate
Stirrer
Stirrer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPER-NUOVA 1359 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Thermo Scientific SUPER-NUOVA 1359 Series

Summary of Contents for Thermo Scientific SUPER-NUOVA 1359 Series

  • Page 1 SUPER-NUOVA Multi-Place Stirrer and Stirring Hot Plates OPERATION MANUAL AND PARTS LIST SERIES 1359 and 1360 Model # Voltage Description S136030-33 220-240 Stirrer S136035 Stirrer SP135930-33 220-240 Stirring Hot Plate SP135935 Stirring Hot Plate LT1359X1 • 10/27/09...

  • Page 2: Table Of Contents

    Table of Contents Safety Information ..............................3 Alert Boxes ..............................3 Warnings ..............................3 General Specifications ............................5 Heating Specifications ..........................6 Stirring Speed Specifications........................6 Environmental Conditions ..........................7 Declaration of Conformity ..........................7 Introduction................................8 General Usage..............................9 Unpacking and Installation ..........................10 Unpacking ..............................10 Installation ..............................10 Principles of Operation............................12 Operation ................................13 Power Button ..............................13 Using the Stirring Function ........................13...

  • Page 3: Safety Information

    Safety Information Your Thermo Scientific SUPER-NUOVA Multi-Place Plate has been designed with function, reliability, and safety in Alert Signals mind. It is your responsibility to install it in conformance with local electrical codes. For safe operation, please pay attention to the alert signals throughout the manual.
  • Page 4 AFETY NFORMATION result. Unit contains components which may ignite such materials. Keep top surface clean. Use a non-abrasive cleaner. Alkali spills, hydrofluoric acid spills or phosphoric acid spills may damage top and lead to thermal failure. Unplug unit and remove spills promptly.

  • Page 5: General Specifications

    General Specifications Stirring Hot Plates Model Number SP135935 SP135930-33 Overall Dimensions in. (cm) Width 11.3” (28.7 cm) 11.3” (28.7 cm) Height 4.0” (10.1 cm) 4.0” (10.1 cm) Depth 16.2” (41.1 cm) 16.2” (41.1 cm) Weight lbs (kg) 20.5 lbs (9.3 kg) 20.5 lbs (9.3 kg) Top Plate Width...

  • Page 6: Heating Specifications

    ENERAL PECIFICATIONS Heating Specifications Top Plate Surface - Solid Ceramic Temperature range: 1°C - 370°C (34°F - 698°F)* * This plate does not cool. The minimum temperature is 1°C if used in a cold room below 1°C. Heat-up time to within 5°C of maximum temperature (unloaded top plate): 8 minutes Temperature stability using remote probe (500 ml of water in a 1000 ml ±1.0°C...

  • Page 7: Environmental Conditions

    ENERAL PECIFICATIONS Environmental Conditions Operating: 0°C to 27°C; 20% to 80% relative humidity, non-condensing. Installation category II (overvoltage) in accordance with IEC 664. Pollution degree 2 in accordance with IEC 664. Altitude Limit: 2,000 meters. Storage: -25°C to 65°C 10% to 85% relative humidity Declaration of Conformity (for 220-240 volt, -33 CE models only) We hereby declare under our sole responsibility that this product conforms with the technical requirements of...

  • Page 8: Introduction

    Introduction Please read all the information in this manual before operating the unit. Your SUPER-NUOVA Multi-Place plate is a heating and/or stirring plate designed for laboratory procedures requiring precise control of temperature and/or stirring speed. Each SUPER-NUOVA Multi-Place includes a digital display for monitoring temperature and/or stirring speed, and the stir- ring hot plate models have dual displays so temperature and stirring speed can be monitored simultaneously.

  • Page 9: General Usage

    NTRODUCTION al purpose heating applications and/or general laboratory mixing of solutions, including sample preparation, heating reagents, melting paraffin, warming resinous chemicals, content analysis, solvent evaporations, digestions, media preparation and sterilization, titrations, sand baths, and microscale chemistry applications. General Usage Do not use this product for anything other than its intend- ed usage.

  • Page 10: Unpacking And Installation

    Unpacking and Installation Unpacking Warning Remove your SUPER-NUOVA Multi-Place from the car- Use a properly grounded electrical ton. Inspect to ensure that the unit has not been damaged outlet of correct voltage and current during shipment. If the unit appears to have sustained handling capacity.
  • Page 11 NPACKING AND NSTALLATION RS232 Port Connections Cord retention clip Remote Probe Connection Below is the control panel of the SUPER-NUOVA Multi-Place stirring hot plate. The stirrer control panel is the same except for any buttons referring to temperature. Speed Set Temperature Temperature Power Button...

  • Page 12: Principles Of Operation

    Principles of Operation Each SUPER-NUOVA Multi-Place utilizes the latest micro- processor technology to deliver the most reliable, accu- rately controlled, ceramic top plate on the market. Your SUPER-NUOVA Multi-Place has an electronic, closed-loop feedback control which will maintain tempera- ture setpoints from 1°C through 370°C. The SUPER-NUOVA Multi-Place plates use a Type K thermocouple for measuring the top plate temperature, OTP and the external probe.

  • Page 13: Operation

    Operation Power Button The SUPER-NUOVA Multi-Place has a power button Note located on the front control panel. The unit may be pow- When the unit is initially plugged into ered on by pressing the power button or ANY button on a power source, or when it is the control panel.
  • Page 14 PERATION Once the unit begins stirring, the display will register ACTUAL speed until the setpoint has been reached. To check the setpoint, press the corresponding stirring posi- Note tion key (1-4 or “SET ALL”) and your setpoint will be dis- Each motor can be paused individu- played again for a few seconds.

  • Page 15: Using The Heating Function

    PERATION Warning Use caution when heating volatile Using the Heating Function materials; top surface and element The SUPER-NUOVA Multi-place stirring hot plate has an can reach the “Flash Point electronic closed-loop feedback control which will main- Temperature” of many chemicals. tain temperature setpoints from 1°C above ambient These plates are not explosion proof.

  • Page 16: Controlling Solution Temperature With An External Probe

    PERATION Controlling Solution Temperature Using External Probe To control the solution temperature plug the included probe or an ungrounded Type K thermocouple probe into the probe receptacle located on the right side of the unit. Be careful to observe the correct polarity of the probe connector when inserting probe.

  • Page 17: Using Preset Programs

    PERATION Using Preset Programs The SUPER-NUOVA Multi-Place features the option of pre- setting 3 setpoints into its memory (A, B or C.) To program a preset, adjust the heat and/or stir features to your desired setpoints. Press and hold one of the presets and the unit will beep indicating those setpoints have been stored in memory.

  • Page 18: Power Interruption Protection

    PERATION If at any time you wish to reset the timer, press the right or left arrow keys until the indicator light corresponds to your desired time. The unit will beep indicating it has been reset. One minute before shutdown, the unit will beep three times and flash the 1 hour light.

  • Page 19: Rs232 Output

    PERATION RS232 Output An RS232 port is available on the SUPER-NUOVA Multi- Place to output elapsed time, speed, and temperature data. The data is printed once every second when the unit is pow- ered on (displays on). A comma separates each piece of data so that it may easily be imported into a spreadsheet as CSV (Comma Separated Values).

  • Page 20: Using Hyperterminal W/Rs232

    PERATION Using HyperTerminal w/RS232 With HyperTerminal you can store the RS232 output data of a SUPER-NUOVA Multi-Place on a PC. NOTE: Other terminal programs that capture RS232 data can be used as well. In order to follow this procedure, you must have: •...

  • Page 21: To Capture Data W/Hyperterminal

    PERATION Select FILE, SAVE AS, and save this setup wherever you would like it to be located (if you would like it on the Desktop, select Desktop) and select SAVE. You will be able to run HyperTerminal with this setup in the future by just double-clicking the icon if you put it on the Desktop.

  • Page 22: Service And Calibration

    Service and Calibration Service Menu The Service Menu has many features that will allow a user to customize their unit. A table of the features available in the Service Menu is given below. The features are given in order of their appearance in the Service Menu when rotating the center knob in a clockwise rotation.

  • Page 23: Over-Temperature Set Point - Osp

    ERVICE AND ALIBRATION Over-temperature Set Point - Note For most routines, the POWER key This option is only available for units that have heating can be used to return to a previous functionality. The Over-temperature Set Point is the set menu if desired.

  • Page 24: Temperature Probe Calibration - Cal

    ERVICE AND ALIBRATION Temperature Probe Calibration - CAL This section applies only to the calibration of the temperature probe system. The hot plate surface and the motor speed cannot be calibrated. This method is only applicable to units that have heating functionality. There are two types of calibration available.

  • Page 25: Oil Bath Method Of Calibration

    ERVICE AND ALIBRATION Oil Bath Method of Calibration With the probe connected to the unit, insert the probe connected to the unit to be calibrated into a bath that has stabilized at the desired calibra- tion temperature. Allow sufficient time for the probe to stabilize.

  • Page 26: System Method Of Calibration

    ERVICE AND ALIBRATION System Method of Calibration Select an independent temperature probe to be placed in the load, along with the unit tempera- ture probe before continuing with calibration. Select the load to be calibrated, and place on top of the hot plate. Place a stir bar in the mix- ture if stirring is desired and available on the unit being calibrated.
  • Page 27 ERVICE AND ALIBRATION If the unit undergoing calibration does not have stirring capability then skip to the next step. The SET indicator under the STIR display will be lit, and the displays will show the stirring control set point. The speed may be adjusted by using the center knob.

  • Page 28: Thermometer Mode - Prb

    ERVICE AND ALIBRATION Thermometer Mode - Prb This option is only available for units with heating function- ality. The Thermometer Mode can be used to display tem- perature using the probe without the heating control on. Stirring can also be independently used if desired . NOTE: Heating will suspend while in thermometer mode.

  • Page 29: Probe Temperature Limit - Pl

    ERVICE AND ALIBRATION To modify/view the Timer Shutdown follow the instructions given below: Plug the unit into the appropriate power, but do not turn it ON (displays should be blank, unless Hot Top Warning System is indicating a hot sur- face), enter the Service Menu by pressing and holding the POWER key.

  • Page 30: Probe Response - Pr

    ERVICE AND ALIBRATION Rotate the center knob until the display reads PL. Press the SET key under the HEAT display to accept, and the display will change to 250 (250°C limit), or UL (unlimited). Rotate the cen- ter knob to change the display to the method of choice and press the SET key under the HEAT display again.

  • Page 31: Set Point Limit - Sl

    ERVICE AND ALIBRATION Set Point Limit - SL This feature is available for units with heating functionali- ty. The purpose of this feature is to select whether the maximum set point will be limited based on the Over-tem- perature Set Point (OSP), or unlimited (UL). If it is limited by OSP then the maximum set point that can be chosen will be based on the setting of the OTP control on the front edge of the unit.

  • Page 32: Factory Defaults - Def

    ERVICE AND ALIBRATION To modify/view the Error Disable menu follow the instruc- tions given below: Plug the unit into the appropriate power, but do not turn it on (displays should be blank, unless Hot Top Warning System is indicating a hot sur- face), enter the Service Menu by pressing and holding the POWER key.

  • Page 33: Model Selection - Sel

    ERVICE AND ALIBRATION a single beep will be heard and you may remove your finger from the POWER key. The display will change to OSP. Rotate the center knob until the display reads dEF. Press either SET key to accept, and the display will change to no.

  • Page 34: Flash Upgrade - Fls

    ERVICE AND ALIBRATION Flash Upgrade - FLS This feature is available for all units and is designed to allow a firmware upgrade via RS232 port to be applied without exchanging controls. NOTE: Special software and an RS232 cable are required to complete this proce- dure.

  • Page 35: Troubleshooting Guide

    Troubleshooting Error Codes y t i . ) t y t i y t i . t r . t i u l i . ) t u l i u l i . t i l i a l i a y t i y t i .
  • Page 36 ROUBLESHOOTING u l i . t i r r i u l i u l i . t i u l i c i t c i t l i a u l i Errors E01 through E07 are heating errors. Error Handler will lock out heating functions if heating error is detected.

  • Page 37: Exploded Views

    Exploded Views Multi-Place Stirrer – Exploded View...
  • Page 38 XPLODED IEWS Multi-Place Stirring Hot Plate – Exploded View...
  • Page 39 XPLODED IEWS Note routing of leads and thermocouple Number located this side Multi-Place Stirring Hot Plate - Top Assembly...
  • Page 40 XPLODED IEWS Multi-Place Stirrer - Top Assembly...

  • Page 41: Wiring Diagram

    Wiring Diagrams SPEED SENSORS Multi-Place Stirrer - Wiring Diagram...
  • Page 42 IRING IAGRAM SPEED SEN NSORS NSORS Multi-Place Stirring Hot Plate - Wiring Diagram...

  • Page 43: Replacement Parts List

    Replacement Parts List To insure your safety and for proper operation, the ceramic top plates for hot plates and stir plates are only sold as complete assemblies. This assembly includes the ceramic top, element, thermocouple, insulation, baffle plate, and 2 ceramic top holders. We recommend not replacing individual components of the top plate.

  • Page 44: Accessories

    Accessories Part No. Description TC732X1 General purpose immersion probe with 6” (15.24 cm) stainless steel sheath TC732X2 General purpose immersion probe with 10” (25.40 cm) stainless steel sheath TC727X2 Chemically-resistant immersion probe with 7” (17.78 cm) Teflon sheath 711S Non-Mercury Thermometer 20 to 100°C Range - 76 mm immersion 647-1S Non-Mercury Thermometer 0 to 110°C Range - 35 mm immersion 1007-3BLS...

  • Page 45: Ordering Procedures

    Ordering Procedures Please refer to the Specification Plate for the complete model number, serial number, and series number when requesting service, replacement parts or in any corre- spondence concerning this unit. All parts listed herein may be ordered from the Thermo Scientific dealer from whom you purchased this unit or can be obtained promptly from the factory.

  • Page 48: Warranty

    (ii) misuse (including use inconsistent with written operating instructions for the product), mishandling, contamination, overheating, modification or alteration of the product by any customer or third party or (iii) use of replacement parts that are obtained from a party who is not an authorized dealer of Thermo Scientific prod- ucts.
