- Page 1 Isotemp Advanced Hot Plates, Stirrers and Stirring Hotplates OPERATING MANUAL AND PARTS LIST CIC0000812 V11 11/29/17 © 2017 Thermo Fisher Scienti c Inc. All rights reserved. Trademarks used are owned as indicated at shersci.com/trademarks.
- Page 2 This manual covers the models shown below NA Model EU Model Voltage Description HP88857290 100-120V 7x7 Ceramic Hot Plate HP88857295 15353528 220-240V-EU 7x7 Ceramic Hot Plate HP88857296 15363528 220-240V-AUS/CHN/UK 7x7 Ceramic Hot Plate S88857290 100-120V 7x7 Ceramic Stirrer S88857295 15373528 220-240V-EU 7x7 Ceramic Stirrer S88857296...
- Page 3 Preface Important Before using this product, read this entire operation manual carefully. Users should follow all of the operational guidelines contained in this manual and take all necessary safety precautions while using this product. Failure to follow these guidelines could result in potentially irreparable bodily harm and/or property damage.
-
Page 4: Table Of Contents
Table of Contents Safety Information ......................... 6 Alert Signals ..........................6 Warnings ............................. 6 Información de seguridad ......................8 Señales de alerta ........................8 Advertencias ..........................9 Sicherheitshinweise ........................10 Gefahrensymbole ........................10 Warnungen ..........................10 Informations de sécurité ....................... 12 Signaux d'alerte .......................... - Page 5 Operation ............................27 Power Switch ..........................27 Setting the Stirring Speed ......................27 Setting the Temperature ......................28 Controlling Solution Temperature Using External Probe ............29 Using Preset Programs ......................29 Heating Metal Vessels and Sand Baths ..................30 Setting the Time .......................... 30 Hardware Over-Temperature-Protection ..................
-
Page 6: Safety Information
Safety Information Your Fisher Scientific Isotemp Advanced hot plate, stirrer Alert Signals or stirring hot plate has been designed with function, reliability, and safety in mind. It is your responsibility to install it in conformance with local electrical codes. For safe operation, please pay attention to the alert signals throughout the manual. - Page 7 AFETY NFORMATION 2.Disconnect from the power supply prior to maintenance 7. Do not remove or modify grounded power plug. Use and servicing. only properly grounded outlets to avoid shock hazard. 8. Use appropriate hand and eye protection when handling To avoid personal injury: hazardous chemicals.
-
Page 8: Información De Seguridad
Información de seguridad Su Plancha Caliente de Agitación Fisher Scientific Isotemp Advanced fue diseñada con la función, la fiabilidad y la seguridad en mente. Para su instalación es su responsabilidad hacerlo en conformidad Señales de alerta con los códigos eléctricos locales. Para su seguro funcionamiento, por favor, preste atención a las señales de alerta especificados en el manual. -
Page 9: Advertencias
nformación eguridad Si esta aflojado, el cable se podría calentar y/ Advertencias o provocar chispas siendo un peligro potencial de incendio. Sustituya el cable inmediatamente si el cable Para evitar descarga eléctrica, siempre: está dañado. Si el cable se afloja continuamente se 1. -
Page 10: Sicherheitshinweise
Sicherheitshinweise Ihre Fisher Scientific Isotemp Advanced Rühr- Heizplatte wurde unter den Gesichtspunkten der Funktionalität, Zuverlässigkeit und Sicherheit entworfen. Es obliegt Ihrer Verantwortung diese in Übereinstimmung mit den Gefahrensymbole örtlichen elektrischen Vorschriften zu installieren. Für einen sicheren Betrieb beachten Sie bitte die Gefahrensymbole in der gesamten Bedienungsanleitung. - Page 11 ICHERHEIT HINWEISE 2. Das Gerät vor der Wartung und Reparatur von der darstellen. Wenn das Kabel beschädigt erscheint, sofort Stromversorgung abtrennen. ersetzen. Wenn das Kabel sich wiederholt lockert, wird es empfohlen, das Netzkabel zu kaufen. Um Verletzungen zu vermeiden: 7. Den geerdeten Netzstecker nicht entfernen oder 1.
-
Page 12: Informations De Sécurité
Informations de sécurité Votre Plaque Chauffante d'Agitatrice Isotemp de Fisher Scientific a été conçue, tout en ayant à l'esprit: la fonction, la fiabilité et la sécurité. Il est de votre responsabilité de l'installer en conformité aux codes électriques locaux. Signaux d'alerte Pour un fonctionnement en toute sécurité, veuillez prêter attention aux signaux d'alerte mentionnés à... -
Page 13: Avertissements
NFORMATION DE ÉCURITÉ aussi devenir un risque d'incendie potentiel. S’il y a Avertissements des endommagements, on doit remplacer la corde immédiatement. Si la corde se desserre plusieurs fois, Pour éviter tout risque de choc électrique, on vous recommende d'acheter la corde d'alimentation. toujours: 7. -
Page 14: Informação De Segurança
Informação de Segurança A Chapa Eléctrica Isotemp Térmica de Fisher Scientific foi desenhada com funcionalidade, confiança e segurança em mente. É sua responsabilidade instalar de acordo com os regulamentos eléctricos locais. Para operação segura, Sinais de Aviso preste atenção aos sinais de alerta presentes no manual. Aviso: Estes produtos devem ser unicamente utilizados sob as condições de operação especificadas no Manual de Utilização. - Page 15 NFORMAÇÃO DE EGURANÇA 2. Desligue sempre a alimentação antes da manutenção e imediatamente. Se o cabo se afrouxar com frequência, assistência. é recomendada a aquisição do cabo de alimentação. Para evitar ferimentos pessoais: 7. Não retire nem modifique a ficha de alimentação aterrada.
-
Page 16: Информация По Безопасности
Информация по безопасности Термо нагревательная плита Термо Фишер Сайентифик была разработана с функцией надежностью и безопасности. Вам необходимо установить ее в соответствии с местными нормативами. Для безопасной Сигналы тревоги эксплуатации, пожалуйста, обратите внимание на сигналы тревоги по всему руководству. Предупреждение: Данные продукты следует использовать... -
Page 17: Предупреждения
И б нформация по езопасности 6. Проверить и заменить съемный кабель, в процессе Предупреждения проверяя безопасность. Если кабель слабо затянут, то он может нагреваться\или искрить, что может Во избежание поражения электрическим быть причиной возгорания. Если кабель поврежден, шоком , всегда : его... -
Page 18: General Specification
General Specification Ceramic Top Hot Plate Specifications HP88857295 HP88857296 HP88857290 (NA) (NA) Overall Dimensions (NA) 15353528 15363528 (EU) (EU) Width - in.(cm) 8.2 (20.8) 8.2 (20.8) 8.2 (20.8) Height - in.(cm) 4.1 (10.5) 4.1 (10.5) 4.1 (10.5) Depth - in.(cm) 14.2 (36) 14.2 (36) 14.2 (36) -
Page 19: Ceramic Top Stirring Hotplate Specifications
ENERAL PECIFICATIONS Ceramic Top Stirring Hotplate Specifications SP88857295 SP88857296 SP88857290 (NA) (NA) Overall Dimensions (NA) 15393528 15303538 (EU) (EU) Width - in. (cm) 8.2 (20.8) 8.2 (20.8) 8.2 (20.8) Height - in. (cm) 4.1 (10.5) 4.1 (10.5) 4.1 (10.5) Depth - in. (cm) 14.2 (36) 14.2 (36) 14.2 (36) -
Page 20: Heating Specifications
ENERAL PECIFICATIONS Heating Specifications* Top Plate Surface - Solid Ceramic Models 7” x 7” 10” x 10” Temperature range 30°C - 450°C (86°F - 842°F)** 30°C - 400°C (86°F - 752°F)** Heat-up time to maximum temperature (unloaded top 5 minutes 7 minutes plate) Accuracy of the temperature display vs. -
Page 21: Declaration Of Conformity
ENERAL PECIFICATIONS Environmental Conditions Operating: 5°C to 35°C; 20% to 80% relative humidity, non-condensing.Installation category II (overvoltage) in accordance with IEC 664. Pollution degree 2 in accordance with IEC 664. Altitude Limit: 2,000 meters. Storage: -25°C to 65°C 10% to 85% relative humidity Declaration of Conformity We hereby declare under our sole responsibility that this product conforms with the technical requirements of the following standards:... -
Page 22: Introduction
Introduction Please read all the information in this manual before operating the unit. Your Isotemp Advanced hot plate, stirrer or stirring hot plate is a heating and/or stirring plate designed for laboratory procedures requiring precise control of temperature and/or stirring speed. Each Isotemp Advanced model includes a liquid crystal display for monitoring actual and setting temperature and/or stirring speed. -
Page 23: Unpacking And Installation
Unpacking and Installation Warning Unpacking Use a properly grounded electrical outlet Remove your Isotemp Advanced unit from the carton. of correct voltage and current handling Inspect to ensure that the unit has not been damaged capacity. during shipment. If the unit appears to have sustained shipping damage contact the distributor from whom you Do not remove or modify grounded power purchased this product or Customer Service at 800-553-... -
Page 24: Isotemp Advanced Hot Plate Control Panel
NPACKING AND NSTALLATION Isotemp Advanced Hot Plate Control Panel Isotemp Advanced Stirrer Control Panel PROGRAM 巨］ 巨］ ＼ Isotemp Advanced Stirring Hot Plate Control Panel... -
Page 25: Control Panel
NPACKING AND NSTALLATION Control Panel Description CAUTION! HOT TOP Indicator Display Knob Temperature Set Button Speed Set Button Time Set Button Program Buttons... -
Page 26: Principles Of Operation
Principles of Operation Each Isotemp Advanced unit utilizes the latest microprocessor technology to deliver the most reliable, accurately controlled, ceramic top or aluminum top hot plate on the market. Your Isotemp Advanced unit with heating functionality has an electronic, closed-loop feedback control which will accurately maintain temperature setpoints from 30°C through 300°C, 400°C or 450°C depending on models. -
Page 27: Operation
Operation Power Switch The Isotemp Advanced unit has Power Switch on the left Warning side of the unit. The unit is powered on by pressing the Use caution when heating volatile Power Switch. When the unit is turned on, the unit will initialize and then model name will be displayed on the first materials;... -
Page 28: Setting The Temperature
PERATION Setting the Temperature Note Boiling times are dependent on solu-tion The Isotemp Advanced heating unit has an electronic volume and the surface area of the flask that closed-loop feedback control which will accurately is exposed to the hot plate. For example, maintain temperature setpoints from 30°C through when heating the same amount of solution in 300°C, 400°C or 450°C(depending on the model). -
Page 29: Controlling Solution Temperature Using External Probe
PERATION Controlling Solution Using Preset Programs Temperature Using External The Isotemp Advanced unit features the option of Probe presetting 3 setpoints into its memory. To set a preset, To control the solution temperature plug a PT100 probe press any "preset" button, and the indicator LED on the into the probe receptacle located on the back side of number button will be illuminated. -
Page 30: Heating Metal Vessels And Sand Baths
PERATION Another mode is timming mode. when the display shows "HOLD", the timer records the total running duration. Heating Metal Vessels and Sand Baths Metal vessels and sand baths cannot be heated on most solid ceramic tops because of the tendency for the metal and the sand to reflect heat back into the top, eventually exceeding the maximum temperature rating for a ceramic top, which causes it to break. -
Page 31: System Configuration
System Configuration The System Configuration has four features that will allow Feature column is the name of the feature, the Display a user to customize their unit. column is the designation of that feature as shown on the display of the unit, the Availability column gives which A table of the features available in the System type of unit the feature is applicable (HP = hot plate SP = Configuration is given below. -
Page 32: Temp Unit
ystem onfiguration This is helpful if there is a failure of the main control that would cause the top to heat excessively. Typically the Temp Unit set point will be adjustable from 60 to 350°C, 450°C or This option is only available for units that have heating 500°C(depending on the model). -
Page 33: Preset Continue
ystem onfiguration the probe connected. Preset Continue Before calibrate the probe, connect the probe on the unit and put the probe sensor into the temperature reference. Enter the System Configuration by pressing and holding Enter the System Configuration by pressing and holding the knob. -
Page 34: Troubleshooting
Troubleshooting Handler will lock out stirring functions if stirring error Error Codes is detected. Heating functionality is unaffected. If the condition that caused the error is no longer present, the Error Handler will lock out heating functions if heating unit will clear Errors automatically. error is detected. -
Page 35: Accessories
Accessories NA Order No. EU Order No. Description CIC0001462 15373538 Splash guard protection shield 4", for 4 x 4 Stirrers and Hotplate Stirrers CIC0001463 15383538 Splash guard protection shield 7", for 7 x 7 Stirrers and Hotplate Stirrers CIC0001464 15393538 Splash guard protection shield 10", for 10 x 10 Stirrers and Hotplate Stirrers PT100 External probe, Stainless steel, for all sizes of Hotplates and Hotplate CIC0001465... -
Page 36: Warranty
Warranty When used in laboratory conditions and according to these operation instructions and maintenance, this product is warranted for 36 months against defective materials or workmanship. The 36 month warranty period begins from the delivery date of this product. For product quality or performance issues, contact Fisher Scientific Customer Service. -
Page 37: Weee Compliance
WEEE Compliance WEEE Compliance. This product is required to comply with the European Union’s Waste Electrical Great Britain & Electronic Equipment (WEEE) Directive 2002/96EC. It is marked with the following symbol. Fisher Scientific has contracted with one or more recycling/disposal companies in each EU Member State, and this product should be disposed of or recycled through them. - Page 38 North America United States Canada 1-800-766-7000 1-800-234-7437 fishersci.com fishersci.ca Europe Austria: Netherlands: +43(0)800-20 88 40 +31(0)20 4887 70 00 at.fishersci.com nl.fishersci.com Belgium: Norway: +32(0)56 260 260 +47 22 95 59 59 be.fishersci.com fishersci.no Denmark: Portugal: +45 70 27 99 20 +351 21 425 33 50 fishersci.dk pt.fishersci.com...
