- Page 1 尺寸：175*130MM 页数：16P 材质：200G铜版纸 印刷要求：双面彩色印刷+封面复亚膜+骑马钉 Yealink Network Technology CO., LTD Yealink VC110 Video Conferencing Endpoint Quick Start Guide Applies to firmware version 50.21.0.20 or later V21.20...
-
Page 3: Table Of Contents
Table of Contents Packaging Contents VC110-All-in-one Unit Connection Diagram Remote Control and Cable Ties Installation VC110-All-in-one Unit Installation Cable Hub Connection Diagram Main Screen Network Deployment Troubleshooting... -
Page 5: Packaging Contents
Wireless Microphone Package Velcro 2 Please use the Yealink-customized DVI cable (only for VC110) VC110 all-in-one unit can work with the video conferencing microphone array, video conferencing wireless microphone or video conferencing phone. You can purchase any combination according to your needs. -
Page 6: Vc110-All-In-One Unit Connection Diagram
VC110 All-in-one Unit Connection Diagram The Back of the VC110 DVI Cable HDMI Cable Display Cable Hub Please connect to Display1 port in blue color if you have only one display device... - Page 7 The VCM60 video conferencing wireless microphone and dongle are automatically ”paired” at the factory. All you need to do is connect the dongle to one of the USB ports on the VC110 all-in-one unit. After the VCM60 is turned on, the VCM60 will register with the dongle automatically.
-
Page 8: Remote Control And Cable Ties Installation
Remote Control and Cable Ties Installation Install batteries Fasten the cables with the cable tie... -
Page 9: Vc110-All-In-One Unit Installation
Hanging Mode Please choose the following installation mode when the thickness of the TV is between 35-120mm. Steps: Lock the VC110 all-in-one unit to the L-bracket. Remove the protection of the Velcro. Put the L-bracket on the Make sure the back of the TV is clean, and then adjust the bracket to ensure close adhesion to the back of top of the TV. - Page 10 Punch holes & Insert expansion bolts Drive screws Adjust the screw position and manually lock it Insert screws to lock the bracket to the wall Connect DVI cable Lock the camera The recommended height for VC110 all-in-one unit positioning is 1.5m-1.8m...
-
Page 11: Cable Hub Connection Diagram
Connect to a video conferencing phone or VCM30 audio device VCM30 video conferencing phone The VC110 video conferencing endpoint should be used with Yealink original power adapter (12V/2A) only. The cable hub can also be powered from a PoE-compliant switch or hub. Wall Mount Method for the Cable Hub To hang the cable hub on the wall, you need to purchase the screws (specification: T4 30) separately. -
Page 12: Main Screen
Main Screen Endpoint IP address and Time and date Site name Status icon account information... -
Page 13: Network Deployment
1）You can sign into the 9-digit enterprise Cloud account using PIN code or username/password (enterprise Cloud account can be managed via Yealink VC Cloud Management Service) 2）You can also use 7-digit build-in Cloud number (build-in Cloud number cannot be managed via Yealink VC Cloud Management Service) - Page 14 Head Office If you deploy VC110 in the head office, at least one static public IP address is required in the head office to allow branch offices to connect. Do one of the following to deploy VC110: Option1: To deploy the VC110 on a public network, at least one static public IP address is required, you need to assign a static public IP address to the VC110.
- Page 15 Configure Port Mapping If the VC110 is deployed in an Intranet, and you want to solve the interconnection problem by port mapping, you must forward the following ports to the public network on the firewall. Function...
- Page 16 If you delpoy VC110 in the branch office, do one of the following to deploy it: Option1: Deploy the VC110 following the same steps as for the head office. In this way, both inbound and outbound calls will be available.
-
Page 17: Troubleshooting
Assume that you are A in head office and use the configuration method in "Head Office" chapter on page 10, you are able to call B in branch office or Yealink Demo, but they cannot reach you. The most likely reason is the firewall or gateway in the environment does not support H.323 ALG feature. - Page 18 . Select Auto from the Type pull-down list, the endpoint will obtain public IP address automatically. If the endpoint does not obtain a public IP address automatically, select Manual Settings from the Type pull-down list, and then enter the public IP address in the Public IP Address field. Yealink Test Room IP: 117.28.251.50、117.28.251.51...
- Page 20 For more information, visit the Yealink website: www.yealink.com YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. Web: www.yealink.com Addr: 309, 3th Floor, No.16, Yun Ding North Road, Huli District, Xiamen City, Fujian, P.R. China Copyright©2016Yealink Inc.All right reserved.
