- Page 1 Yealink VC110 Video Conferencing Endpoint Quick Start Guide V10.6 Applies to 50.10.0.6 firmware version or later...
-
Page 2: Table Of Contents
Table of Contents Packaging Contents Cable Hub Connection Diagram VC110-All-in-one Unit Connection Main Screen Diagram Remote Control and Cable Network Deployment Ties Installation Troubleshooting VC110-All-in-one Unit Installation... -
Page 3: Packaging Contents
Microphone Array Package Wireless Microphone Package Video Conferencing Phone Package Velcro 2 Please use the Yealink-customized DVI cable (only for VC110) VC110 all-in-one unit can work with the VCM60, VCP40 or VCM30. You can purchase any combination according to your needs. -
Page 4: Vc110-All-In-One Unit Connection Diagram
VC110 All-in-one Unit Connection Diagram The Back of the VC110 DVI Cable HDMI Cable Display Cable Hub Please connect to Display1 port in blue color if you have only one display device... - Page 5 The VCM60 video conferencing wireless microphone and dongle are automatically ”paired” at the factory. All you need to do is connect the dongle to one of the USB ports on the VC110 all-in-one unit. After the VCM60 is turned on, the VCM60 will register with the dongle automatically.
-
Page 6: Remote Control And Cable Ties Installation
Remote Control and Cable Ties Installation Install batteries Fasten the cables with the cable tie... -
Page 7: Vc110-All-In-One Unit Installation
VC110 All-in-one Unit Installation Hanging Mode Please choose the following installation mode when the thickness of the TV is between 35-120mm. Steps: Lock the all-in-one unit Remove the protection of the Velcro Install bracket Make sure the back of the TV is clean, and then adjust the bracket to ensure close adhesion to the back of the TV with Velcro... - Page 8 Punch holes & Insert expansion bolts Drive screws Adjust the screw position and manually lock it Insert screws to lock the bracket to the wall Connect DVI cable Lock the camera The recommended height for VC110 all-in-one unit positioning is 1.5m-1.8m...
-
Page 9: Cable Hub Connection Diagram
Connect to a VCP40 or VCM30 audio device VCM30 VCP40 The VC110 video conferencing endpoint should be used with Yealink original power adapter (12V/2A) only. The cable hub can also be powered from a PoE-compliant switch or hub. Wall Mount Method for the Cable Hub To hang the cable hub on the wall, you need to purchase the screws (specification: T4 30) separately. -
Page 10: Main Screen
Main Screen Endpoint IP address and Time and date Site name Status icon account information... -
Page 11: Network Deployment
Configuration suggested : . To deploy the VC110 on public network, you need to assign a static public IP address to it. . To deploy the VC110 in an Intranet, you need to assign a static private IP address behind the firewall. - Page 12 . Press 【Save】 to save the configuration, then the screen prompts【Reboot now】. Press 【OK】 to reboot the endpoint. Configure Port Mapping If the VC110 is deployed in Intranet, you need to finish the following port mapping on the firewall: Function Port Protocol Type H.323 signal port...
- Page 13 Branch Office If you are in branch office, following two options are suggested: Option1: Deploy the VC110 following the same steps as in the head office. In this way, both inbound and outbound calls are available. Option2: Deploy the VC110 using intelligent firewall traversal way. In this plug and play way, firewall configuration is not required, but only outbound calls are allowed.
-
Page 14: Troubleshooting
Assume that you are A in head office and use the configuration method in "Head Office" chapter on page 9, you are able to call B in branch office or Yealink Demo, but they cannot reach you. The most likely reason is the firewall or gateway in the environment does not support H.323 ALG... - Page 15 In this situation, please do as follows to enable NAT feature on VC110 to solve this problem. (Do these steps by the remote control) . Menu->Advanced (admin password: 0000)->NAT/Firewall . Select 【Auto】 from the 【Type】 pull-down list, the endpoint will obtain public IP address automatically.
- Page 16 For more information, visit the Yealink website: www.yealink.com YEALINK NETWROK TECHNOLOGY CO.,LTD. Web: www.yealink.com Addr: 4th-5th Floor, South Building, No.63 Wanghai Road, 2nd Software Park, Xiamen, China(361008) Copyright©2015Yealink Inc.All right reserved.
