Yealink Network Technology CO., LTD
Yealink VC120 Video Conferencing Endpoint Quick Start Guide
Applies to firmware version 40.20.0.1 or later
V20.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VC120 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yealink VC120

  • Page 1 Yealink Network Technology CO., LTD Yealink VC120 Video Conferencing Endpoint Quick Start Guide Applies to firmware version 40.20.0.1 or later V20.1...
  • Page 3: Table Of Contents

    Table of Contents Packaging Contents Bracket and Camera Installation Main Screen VC120 Connections VCM60 Connections Network Deployment Remote Control and Cable Troubleshooting Ties Installation...
  • Page 4: Packaging Contents

    Wireless Microphone Package Please use the Yealink-customized DVI cable VC120 video conferencing endpoint can work with the VCM60, VCP40 or VCM30. You can purchase any combination according to your needs. We recommend that you use the accessories provided or approved by Yealink. The use of unapproved...
  • Page 5: Vc120 Connections

    Connects to a VCP40 or VCM30 audio device Please connect to the Display1 port if you only have one display device The endpoint should be used with Yealink original power adapter (19V/3.42A) only. The use of the third-party power adapter may cause the damage to the endpoint...
  • Page 6: Vcm60 Connections

    The VCM60 video conferencing wireless microphone and dongle are automatically ”paired” at the factory. All you need to do is connect the dongle to one of the USB ports on the VC120 Codec. After the VCM60 is turned on, the VCM60 will register to the dongle automatically.
  • Page 7: Remote Control And Cable Ties Installation

    Remote Control and Cable Ties Installation Install batteries Fasten the cables with the cable tie...
  • Page 8: Bracket And Camera Installation

    Bracket and Camera Installation Hanging Mode Please chose the following installation mode when the thickness of the TV is between 35-120mm Steps: Lock the Camera Remove the protection of the Velcro Install bracket Make sure the back of the TV is clean, and then adjust the bracket to ensure close adhesion to the back of the TV with Velcro Adjust the bracket to ensure close adhesion to the back of the TV...
  • Page 9 Wall Mount Method Screw specification: M3 8 100mm Hole depth: 30mm Screw specification: T4 30 Hole diameter: 6mm Steps: Punch holes & Insert expansion bolts Drive screws Adjust the screws position and manually lock them Insert screws to lock the bracket to the wall Connect DVI cable Lock the camera The recommended height for camera positioning is 1.5m-1.8m above the ground...
  • Page 10: Main Screen

    Main Screen Endpoint IP address and Time and date Site name Status icon account information...
  • Page 11: Network Deployment

    At least one static public IP address is required in the head office to allow branch offices to connect. The recommended endpoint configurations are as follows : . To deploy the VC120 on a public network, you need to assign a static public IP address to the VC120.
  • Page 12 . Press 【Save】to save the configuration, then the screen prompts【Reboot now】. Press 【OK】 to reboot the endpoint. Configure Port Mapping If the VC120 is deployed in an Intranet, you need to finish the following port mapping on the firewall: Function Port Protocol Type H.323 signal port...
  • Page 13 Option2: Deploy the VC120 using an intelligent firewall, which means that plug and play is possible without any further firewall configuration, but only outbound calls are available. Please note that when the VC120 is deployed with an intelligent firewall, you have to open ports (as shown below) permission if they are restricted It is recommended that you forward the web management port(443/TCP) to the public network, so that the head office can remotely manage the branch office.
  • Page 14: Troubleshooting

    Assume that you are A in head office. Using the configuration method explained in "Head Office" chapter on page 8, you find that you can call B in branch office or Yealink Demo, but that they cannot call you. The most likely reason is that the firewall or gateway in the environment does...
  • Page 15 NAT feature on the VC120 can solve this problem. (Carry out each step via the remote control) . Menu->Advanced(Admin Password:0000)->NAT/Firewall . Select 【Auto】 from the 【Type】 pull-down list, the endpoint will obtain public IP address automatically. . If the endpoint does not obtain a public IP address automatically, select【Manual Settings】...
  • Page 16 For more information, visit the Yealink website: www.yealink.com YEALINK NETWROK TECHNOLOGY CO.,LTD. Web: www.yealink.com Addr: 4th-5th Floor, South Building, No.63 Wanghai Road, 2nd Software Park, Xiamen, China(361008) Copyright©2015Yealink Inc.All right reserved.
