Dash Port Docking
Station Test

Electrical Safety Tests

Operation

RAC 2A Module
Housing Test

Electrical Safety

Operation
Checkout
Procedures
Completion

PM Form

Revision B
MAINTENANCE: Checkout Procedures
When the monitor is connected to the docking station, perform ALL the
tests described in "Electrical Safety Tests," starting on page 4-9.
Complete the "Checkout Procedures" located in the "Dash Port Docking
Station Service Manual."
Because the RAC 2A module housing has a separate power supply,
perform electrical safety tests separate from the monitor.
Refer to the "Electrical Safety Tests" section of this chapter and complete
the following tests.
1. Wall Receptacle Test
2. Ground (earth) Continuity Test,
3. Ground (earth) Wire Leakage Tests, and
4. Enclosure Leakage Current Test.
Complete the "Maintenance Schedule" procedures found in the "RAC 2A
Module Housing Service Manual."
This completes all tests associated with the checkout procedures.
1. Discharge the test patient admitted during the "ECG Tests"on
page 4-21.
2. Set all test equipment power switches to the off position.
3. Unplug the monitor (or docking station) from AC power.
4. Remove all test equipment from the monitor (or docking station).
Due to continuing product innovation and because specifications in this
manual are subject to change without notice, a PM form is not included
with this manual. For the latest PM form regarding this product, contact
GE Service.
If repairs/adjustments were made or any parts replaced, describe this in
the area provided on the PM form.
Also include comments regarding any unusual environmental conditions
that may affect the operation or reliability of the equipment in the area
provided on the PM form.
On the following pages a repair log is included for your convenience to
record the repair history of this product.
Dash 3000/4000 Patient Monitor
2000966-105
4-41
