FIELD REPLACEABLE UNITS AND UPGRADES: Main Unit Components
8-20
6. If you need to replace the DAS assembly, attach the NBP
assembly to the new DAS assembly.
If you need to replace the NBP assembly, attach the new NBP
assembly to your unit's DAS assembly.
7. Reassemble the DAS and NBP assemblies. Make sure you do not
forget:
• the four mounting screws,
• the tube connection, and
• the flex connector.
8. If you installed the Masimo SET SPO2 upgrade, place the labels as
shown.
patent disclosure label
9. Reassemble the monitor in reverse order.
Dash 3000/4000 Patient Monitor
2000966-105
Masimo SET label
827A
828A
