Display Test; Speaker Test; Network Test; Remote Control Test - GE Medical Systems Dash 3000 Service Manual

Display Test

Speaker Test

Network Test

Remote Control Test

RF LAN Test (option)

4-40
MAINTENANCE: Checkout Procedures
1. Hold the NBP GO/STOP and the ZERO ALL keys and press the
Trim Knob control at the same time.
2. Release the Trim Knob control immediately.
3. Continue holding the NBP GO/STOP and the ZERO ALL keys.
4. Select "Video Test Screens."
5. Test all screens:
• White Screen.
• Red Screen.
• Blue Screen.
• Green Screen.
• Vertical Bars.
1. Change the alarm volume of the monitor to 100%.
2. Verify the speaker volume of the monitor changes accordingly.
3. Return the volume of the monitor to the level it was previously set to,
before you changed it for this test.
1. Verify that the monitor is connected to the Unity-MC (Mission
Critical) network.
NOTE: When the monitor is connected to a docking station, verify
the docking station is connected to the Unity-MC network.
2. Select VIEW OTHER PATIENTS.
3. Select SELECT ANOTHER CARE UNIT.
4. Verify that you can see at least one care unit.
5. Select a care unit.
6. Select SELECT A BED TO VIEW.
7. Select a bed.
8. Verify that the patient window appears on the monitor's split-screen.
1. Verify the remote control is connected into an Autoport to Mport
adapter and is inserted into the Aux connector.
2. Select MORE MENUS -> MONITOR SETUP -> REVISION AND ID.
3. Select NEXT from the popup menu to display the port connectors.
4. Verify the REMOTE CONTROL label appears after the appropriate
port and the software version for the remote control is 1A.
5. Press each remote control key and verify a beep tone sounds at the
monitor.
1. If the monitor has the Wireless LAN, disconnect the Ethernet cable
and verify Wireless LAN communication still exist between beds,
2. Reconnect the Ethernet Cable.
3. Return to the MAIN MENU.
Dash 3000/4000 Patient Monitor
2000966-105
Revision B
