Software Packages And Software Options - GE Medical Systems Dash 3000 Service Manual

EQUIPMENT OVERVIEW: Software Packages and Software Options

Software Packages and Software Options

Software Packages
Software Options
2-10
The Dash monitor comes configured with the Basic software package.
This package consists of standard-of-care parameters, lethal arrhythmia
detection, dose calculations, and features required by clinicians caring
for acutely ill patients.
Two additional software packages can be purchased separately or in any
combination. These packages provide a variety of features which allow
the monitor to be configured to best meet the needs of its intended
environment.
The Cardiac software package focuses on cardiac conductivity. Its
features include full arrhythmia analysis and storage, as well as ST
segment trending, storage, and templates. The ability to adjust the ST
measurement point is also included in this package.
The Cardiopulmonary software package centers upon cardiac and
pulmonary hemodynamics. Features include the PA insert and wedge
algorithms, the intra-aortic balloon pump algorithm, and the
thermodilution cardiac output algorithm, including predefined
computation constants for the catheters of major manufacturers. Also
included are cardiac and pulmonary calculations.
Three software options can be purchased separately or in any
combination with the software packages and software options.
The High Resolution CRG Trends option provides storage of up to 100
CRG events, and up to 24 hours of CRG trend data, in addition to the
CRG feature set found in the Basic software package.
The 12SL ECG analysis program with Gender Specific Criteria and the
Acute Cardiac Ischemia–Time Insensitive Predictive Instrument (ACI-
TIPI) analysis option uses recorded ECG data to produce a numerical
score which is the predicted probability of acute cardiac ischemia. In
addition, the gender specific criteria improves the detection of acute
myocardial infarctions (AMI) in women.
The Unity Network option enables you to view other patients on the
network, interface with a central station and other network devices, and
perform Combo or Rover Combo monitoring.
Dash 3000/4000 Patient Monitor
2000966-105
Revision B
