Danfoss VLT 6000 Manual page 23

Point Factory
Descriptor
Number Default
(SI Units)
{33} LOCK PANEL OPEN
Note 5
{34} SEL HND.AUTO HAND
{35} RUN ENABLE
{36} BUS TIME
{37} BUSTIME FUNC
Note 6
{38} F OUT LOW
Note 3
{39} F OUT HIGH Note 4
Note 3
{40} RELAY OUT 1
{41} RELAY OUT 2
{42} PI STRT FR.
{43} RELAY 1 STA
{44} RELAY 1 STA
{45} CURR. LIM.S Note 4
{46} F OUT LOW.S
{47} F OUT HIGH.S Note 4
{48} REF MIN.S
{49} REF MAX.S Note 4
{50} REF MIN
Note 3
{51} REF MAX Note 4
Note 3
{52} REF STAT OFFREF
{53} BUS REF
{54} SLEEP FREQ.S
{55} WAKEUP FRQ.S Note 4
{56} SLEEP TIME
{57} SLEEP FREQ
Note 3
{58} WAKEUP FREQ Note 4
Note 3
{59} SLEEP MODE
{60} INPUT REF
{61} PI STRT FREQ
Note 3
{62} PI FEEDBACK
{63} PI GAIN
{64} PI I TIME
MG.60.G2.02 - VLT is a registered Danfoss Trademark
SI Units Slope
(SI Units)
-- --
-- --
OFF -- --
60 SEC 2
0 -- 1
0 HZ 0.1
HZ 0.1
Physical Output Points
OFF -- --
OFF -- --
0 HZ 0.1
OFF -- --
OFF -- --
A 0.1
0 HZ 0.1
HZ 0.1
0 UNIT 0.1
UNIT 0.1
Setpoint Related Points
0 UNIT 0.1
UNIT 0.1
-- --
0 -- 1
0 HZ 0.1
HZ 0.1
301 SEC 1
0 HZ 0.1
HZ 0.1
OFF -- --
PI Loop Related Points
0 UNIT 0.1
0 HZ 0.1
0 UNIT 0.1
0.3 -- 0.01
9999 SEC 0.3051543
VLT ® 6000 HVAC
Intercept
Range On Text
(SI Units)
-- -- LOCK
-- -- AUTO
-- -- ON
2 32767 --
0 255 --
0 16383 --
0 16383 --
-- -- ON
-- -- ON
0 16383 --
-- -- ON
-- -- ON
0.1 16383 --
0 16383 --
0 16383 --
-1638.3 32767 --
-1638.3 32767 --
-1638.3 32767 --
-1638.3 32767 --
-- -- ON.REF
0 32767 --
Note 7
0 16383 --
0 16383 --
0 511 --
0 16383 --
0 16383 --
-- -- SLEEP
-1638.3 32767 --
0 16383 --
-1638.3 32767 --
0 1023 --
0.01 32767 --
Read/ Param. Network
Off Text
Write number Port
Type
Note 1
OPEN R/W 12-15 LDO
HAND R 532-13 LDI
OFF W Cmd-6 LDO
-- R/W 565 LAO
-- R/W 566 LAO
-- W 201 LAO
-- W 202 LAO
OFF W Cmd-11 LDO
OFF W Cmd-12 LDO
-- R 422 LAI
OFF R 530-11 LDI
OFF R 530-12 LDI
-- R 215 LAI
-- R 201 LAI
-- R 202 LAI
-- R 204 LAI
-- R 205 LAI
-- W 204 LAO
-- W 205 LAO
OFFREF R 527-8 LDI
-- R/W -- LAO
-- R 404 LAI
-- R 405 LAI
-- R 403 LAI
-- W 404 LAO
-- W 405 LAO
OFF R 532-3 LDI
-- R 510 LAI
-- W 422 LAO
-- R 511 LAI
-- R/W 423 LAO
-- R/W 424 LAO
23
