Danfoss VLT 6000 Manual page 27

Point Descriptor
Number
53 BUS REF
54 SLEEP FREQ.S
55 WAKEUP FREQ.S
56 SLEEP TIME
57 SLEEP FREQ
58 WAKEUP FREQ
59 SLEEP MODE
60 INPUT REF
61 PI STRT FREQ
62 PI FEEDBACK
63 PI GAIN
64 PI TIME
65 PI GAIN LIM
66 LOWPASS FILTER
67 SLEEP BOOST
68 FB FUNC
69 SETPOINT 1
70 SETPOINT 2
71 FB MIN
72 FB MAX
73 BUS FB 1
74 BUS FB 2
75 AUTO RAMP
76 VOLT STAT
77 INVERT STAT
78 FREQ STAT
79 CTRL STAT
80 DRV ENA STAT
81 DRV RDY STAT
82 DRVCTRL STAT
84 RESET
85 START
86 Q.STOP
87 TERM 53
88 TERM 54
89 TERM 60
90 OK.WARNING
91 LAST WARNING
92 OK.FAULT
93 LAST FAULT
94 RESET FAULT
95 SETPOINT 1.S
96 SETPOINT 2.S
97 FB MIN.S
98 FB MAX.S
99 ERROR STATUS
MG.60.G2.02 - VLT is a registered Danfoss Trademark
Definition
Sends drive an external reference signal in percent.
Displays status of point 57.
Displays status of point 58.
Displays run time at low speed before sleep mode starts.
Sets output frequency required to activate sleep mode timer.
Sets command frequency required to restart motor after sleep mode.
Displays when drive is stopped in sleep mode.
Displays drive input reference in Hz or as selected in parameter 415.
Sets drive frequency after start at which PID control is activated.
Displays resulting feedback value in units selected in parameter 415.
Sets proportional gain of PID controller in percentage.
Sets integral time of PID controller in seconds.
Sets maximum gain for differentiator of PID controller.
Sets lowpass filter time constant for feedback circuit.
Displays sleep boost set point in percentage.
Selects calculation method when two feedback signals are used.
Sets setpoint for feedback 1 in units selected in parameter 415.
Sets setpoint for feedback 2 in units selected in parameter 415.
Sets minimum feedback signal value in units selected in parameter 415.
Sets maximum feedback signal value in units selected in parameter 415.
Supplies feedback value for bus feedback 1 in percent.
Supplies feedback value for bus feedback 2 in percent.
Displays when drive deceleration rate is extended due to auto ramping.
Displays if drive DC bus voltage exceeds high/low warning limits.
Displays drive inverter status, ok or stall.
Displays if drive is running outside of frequency limits of parameters 223 and 224.
Displays whether drive is in local control or FLN serial bus.
Displays if drive is enabled to start when run command given.
Displays if drive control is ready or if a trip has occurred.
Displays drive control status as ready or not ready.
Displays if a fault reset command has been given via serial bus.
Displays if a run command has been given via serial bus.
Displays if a stop command has been given via serial bus.
Displays voltage value of signal on terminal 53 in volts.
Displays voltage value of signal on terminal 54 in volts.
Displays current value of signal on terminal 60 in mA.
Displays if drive is in a warning condition.
Displays last drive warning.
Displays if drive has been tripped due to a fault.
Displays last drive fault trip.
Resets drive faults and resumes normal drive operation.
Displays status of point 69.
Displays status of point 70.
Displays status of point 71.
Displays status of point 72.
Not used.
VLT ® 6000 HVAC
27
