C B
USTOMIZE THE
Navaids on Bird's Eye View allows you to add navigational aids to the Bird's Eye View, such as lights or buoys. The available settings
are determined by the installed map card and the selected map source.
navaids set
to visible
route
off course
limits
Show/Hide Navaids
1. Main Menu: Press the MENU key twice. Select the Chart tab.
2. Select Navaids on Bird's Eye View.
3. Select Visible or Hidden.
Show/Hide the Bird's Eye Outline
If you use the Chart/Bird's Eye View, you can display a line on the Chart View that shows the portion of the view that is used in the
Bird's Eye View.
1. Main Menu: Press the MENU key twice. Select the Nav tab.
2. Select 3D View Outline.
3. Select Visible or Hidden.
' E V
IRD S YE IEW
Bird's Eye View
boat icon
Chart/Bird's Eye Combo View
waypoint
121
Chart View

Customize the Bird's Eye View

3D view
outline set
to visible
off course
limits
boat icon
