450x100x380mm ( BxHxT)
Have fun with your new Teufel sound furniture!
Now just connect TV and playback devices and let's go!
For more information - for example, how to upgrade to 5.1 surround sound
- See www.Teufel.de / huelsta
1544447
SERVICE
Stand: 02/2014
hülsta-werke · Karl-Hüls-Straße 1 · 48703 Stadtlohn
TEL +49 2563 86-1500 · FAX +49 2563 86-1417
SEITE 1
www.huelsta.com · info@huelsta.com
Advertisement
Table of Contents
Related Manuals for Teufel hulsta
Summary of Contents for Teufel hulsta
- Page 1 450x100x380mm ( BxHxT) Have fun with your new Teufel sound furniture! Now just connect TV and playback devices and let‘s go! For more information - for example, how to upgrade to 5.1 surround sound - See www.Teufel.de / huelsta 1544447...
-
Page 2: Table Of Contents
CONTENTS Safety notes Menu functions Surround menu Controls and “Tone control” menu Control unit connections “Speaker Levels” menu Remote control unit “Source levels” menu Subwoofer Remote control unit „Audio mapping“ menu Inserting batteries “Speaker Setup” menu Functions Connections “System Setup“ menu Antennas Control unit Special function... -
Page 3: Safety Notes
nal device specifi cations may be used Safety notes for repairs. In this unit there are electri- cal and mechanical components which Signal symbols are essential in order to avoid exposure The following signal symbols can be found to sources of danger. in this instruction manual: •... - Page 4 loudspeakers. Risk of damage! Danger • Prevent damage to your health by avoi- Power overload due to lightning ding extended listening at high volume. strike may damage or destroy the unit. Danger Danger of chemical burns! • If the unit is to be left unsupervised for a Leaking battery acid may lead to long period (e.g.
-
Page 5: Control Unit
Controls and connections No. Name Description SOURCE Change signal source Control unit Front side – Display panel POWER/ Control dial/switch on SELECT button BACK Return button No. Name Description Connector jack for VHF antenna Rear side AM +/ Connector jacks for medium wave antenna 9 1011 12 13 14 15... -
Page 6: Remote Control Unit
No. Name Description 20 SLEEP Sleep function 21 HDMI 1 Select input source – 3 Remote control unit OPTICAL COAXI- AL 1/2 1/2/3 FM/AM 22 1 ... 0 Number buttons 23 FREQU. Radio mode: enter tuning frequency Mute loudspeakers 25 VOL +/– Adjust volume 26 TONE/ Adjust sound,... -
Page 7: Subwoofer
Subwoofer Rear side No. Name Description Analogue 5.1 audio LINE IN 46 47 input jacks AUTO ON Set sensitivity level for LEVEL automatic switch on SUBWO- Subwoofer volume OFER control VOLUME Automatic switch on/off POWER or switch on long-term MODE –... -
Page 8: Inserting Batteries
Remote control unit To operate the remote control unit you re- quire two batteries, type micro or AAA size with 1.5 volts (supplied). Insert batteries • Press lightly on the arrow on the lead of the battery compartment on the rear of the remote control and push the lid downwards and out. -
Page 9: Antennas
Connections Control unit Risk of injury/damage! Danger Arrange the cables so that they do not pose a trip hazard. Antennas Risk associated with lightning Danger strike! If you use outdoor or a roof anten- nas, be absolutely sure that the antenna has lightning protection. -
Page 10: Input Jacks For Playback Sources
Input jacks for playback sources The control unit provides you with three HDMI inputs for digital audio/video signals (“HDMI” 1, 2 and 3), three analogue sound inputs (“AUX” 1, 2 and 3) and one optical and two coaxial sound inputs. HDMI 1, 2 and 3 You can connect one playback source with digital picture and sound signals to... -
Page 11: Outputs
Output jacks TV/Beamer Connect your TV set to jack 17 “HDMI OUT”. To do so you require an HDMI cable. (from HDMI standard 1.4a) Audio outputs Connect your multichannel active subwoofer and/or active loudspeakers to the cinch jacks 15. To do so, you require 3 stereo cinch cables: FRONT LEFT/ Front channels left/... - Page 12 Risk of injury/damage! Danger Reduce the loudspeaker volume before removing the headphones plug, otherwise the loudspeaker might emit sound at an unexpectedly high level. This could injure your ears or damage the unit. Mains connections • Make sure that your end amplifi er, multichannel active subwoofer or the active loudspeakers are switched off.
-
Page 13: Input
Subwoofer connections Input Connect the LINE IN jacks 43 of the subwoofers, using the cinch cables supplied, to the 5.1 output jacks of the control unit. Satellite loudspeakers Check correct polarity! • Connect clips of the same colour. Otherwise sound quality suffers. •... -
Page 14: Mains Connections
Mains connections 1. Make sure that the mains switch 49 “POWER” on the subwoofer is switched off (position “OFF”). 2. Connect the mains connection jack 50 to a mains socket using the mains supply cable. 3. Switch the mains switch 49 “POWER”on the subwoofer to “ON”. -
Page 15: Switching On And Off
Basic functions Switching on and off If the unit is in standby, a red point lights up in display panel 2. • Switch the unit on by briefl y pressing the control dial 3 or button 42 „ “. If the unit is switched on the letters in display panel 2 light up. -
Page 16: Adjusting The Volume
Adjusting the volume • Increase volume: turn control dial 3 clockwise or press button 25 “VOL +”. • Reduce volume: turn control dial 3 anti- clockwise or press button 25 “VOL -”. The selected volume is shown in the section “– – –” (low) up to “10.0 dB”... -
Page 17: Controls
Menu functions The functions of the control unit are set via the menu. This is how to use the menu: • Press control dial 3 “POWER/SELECT” or button 37 “•”. The main menu appears on the connected screen and the display panel 2. -
Page 18: Surround Menu
• Manually: Every time the button is Dolby Digital and DTS (Standard and touched the frequency is increased or reduced by one increment.(FM: 0.05 When playing back Dolby Digital or MHz, AM: 9 kHz). DTS coded multi-channel tracks the sur- •... -
Page 19: Source Levels" Menu
“Source levels” menu System Setup menu You can adjust the relative volume from HDMI “–10” (decrease) to “+10” (increase) for CEC (Consumer Electronics Control) each audio source here. If this function has been activated (ON), CEC compatible devices are controlled “Audio Mapping”... - Page 20 4-8 ohms) via the clips 48 “REAR LEFT/RIGHT”. It is also possible to use a remote-controlled transmission system (such as (e.g. the Teufel RearStation 4). Note: Only select 5.1 if corresponding additional loudspeakers are connected. If 5.1 is selected without additional loudspeakers, there is no Surround transmission.
-
Page 21: Surround
We recommend using a Teufel sound level Special function buttons meter, which you can order from our Surround website www.teufel.de on the accessories page. With button 40 “SURROUND” you can switch the surround mode in the following Channel level buttons... -
Page 22: Tone/Lipsync
Tone/LipSync Sleep With button 26 “TONE/LIPSYNC” you can You want to fall asleep with music? This adjust the sound and the audio delay. automatic deactivation function will help and turns off the control unit after a preset Adjusting sound time elapses (max. 60 mins.). Briefl... -
Page 23: Setting Radio Stations
Radio playback Select one of the 2 radio frequency ranges as a source (see page 15): FM – reception of mono and stereo sta- tions from 87.5 bis 108 MHz, RDS mode possible. AM– reception of mono stations from 522 to 1.629 kHz. - Page 24 Selecting stations from the memory With button 39 “CH +/–” you can select the occupied stations one after another. Entry of the station memory slot number: • Press button 41 “PRESET”.The number of the last memory slot used will appear in the display panel, e.g.
-
Page 25: Troubleshooting
Troubleshooting The following advice should help you to solve problems. If this doesn’t work, please contact our hotline. Take note of the warranty instructions. Problem Possible cause Solution The control unit The device has no power. Check if the mains power plug does not work, the is connected to jack 19 “12V”... - Page 26 With stereo sour- MP3s, radio and many television Use the remote control to ces, for example programmes only have stereo switch the control unit to with radio playback sound. Pro-Logic mode or to one of or an MP3 player, the DSP modes (3.1/5.1 the rear satellites stereo).
- Page 27 Care and cleaning Environmental protection Clean the control unit regularly with a soft, Disposal of the unit damp microfi bre cloth. Please be absolu- Used units must not be dispo- tely sure to observe the following notes in sed of with household waste! the process: If the unit is no longer operatio- Risk of electric shock!
-
Page 28: Technical Data
350 watts Satellites Impedence: 4 - 8 Ohm Dimensions (W x D x H): 95 x 95 x 190 mm Net weight: 1,2 kg Subject to technical alterations! Further technical data can be found on our website www.teufel.de SEITE 28...
