Modbus Register

6. Modbus Register
Register
Address Type
40002 Single Write
Command
40003 Multiple Read
Starter
status
40004 Multiple Read
Trip Code
1
40005 Multiple Read
Motor
current
40006 Multiple Read
Motor
temperature
40007 Multiple Read
Product Type
and Version
40008 Multiple Read
Serial
Protocol
Version
2
40009 ~ Single Write
Parameter and Multiple
management Read
Description
1 = Start
2 = Stop
3 = Reset
4 = Quick stop (coast to stop)
5 = Forced communication trip
Bit Description
0 to 3 1 = Ready
2 = Starting
3 = Running
4 = Stopping (including braking)
5 = Restart delay (including
Temperature check)
6 = Tripped
7 = Program mode
8 = Jog forward
9 = Jog reverse
4 1 = Positive phase sequence (only valid if bit
6 = 1). Always = 0
5 1 = Current exceeds FLC
6 0 = Uninitialised
1 = Initialised
7 Always = 0
See Trip Code table.
Average 3 phase motor current (A)
Motor temperature (thermal model)
Bit Description
0 to 2 Product parameter list version
3 to 7
1= MCD 3000
4= MCD 200
7 = MCD 500
Parameter 1-A (Motor FLC) to:
• MCD 500 Par. 20-6 (Pedestal Detect)
• MCD 3000 Par. 60 (Min Run Frequency)
