Dahua HD IR Vari-Focal Fixed Network Camera User's Manual
Parameter
Main Processor
OS
System
Resources
User Interface
System Status
Image Sensor
Scan Pixel
Day/Night Mode
Gain Control
White Balance
BLC
Electronic
Shutter
Video
Compression
Standard
Video Frame
Rate
Video Bit Rate
Model
IPC-HFW2100R-Z
High performance DSP
Embedded LINUX
Support real-time network monitoring, local record, and remote
operation at the same time.
Remote operation interface such as WEB, DSS, PSS
Bit stream statistics, log, and software version.
1/3-inch CMOS
1280(H)*960(V)
Support day/night mode switch.
Fixed/Auto
Manual/Auto
On/Off
Auto/Manual
It ranges from 1/3 to 1/100000.
H.264/H.264H/MJPEG
PAL:
Main stream
(1280*960@25fps)
Extra Stream 1
(704*576@25fps),
Extra Stream 2
(1280*720@8fps)
NTSC:
Main stream
(1280*960@30fps)
extra stream 1
(704*480@30fps),
Extra Stream 2
(1280*720@1fps)
Note:
The exact frame rate of extra stream 2 is decided by device max
capacity set, it is dynamic and adjustable during the range of max
capacity set.
H.264H: 40Kbps-8192Kbps; adjustable.
IPC-HFW2200R-Z
1/2.8-inch CMOS
1920(H)*1080(V)
PAL:
Main stream
(1920*1080@25fps)
Extra Stream 1
(704*576@25fps),
Extra Stream 2
(1280*720@11fps)
NTSC:
Main stream
(1920*1080@30fps)
Extra Stream 1
(704*480@30fps),
Extra Stream 2
(1280*720@1fps)
IPC-HFW2300R-Z
1/3-inch CMOS
2048(H)*1536(V)
PAL:
Main stream
(2048*1536@20fps)
Extra Stream 1
(704*576@20fps),
Extra Stream 2
(1280*720@1fps)
Main Stream
(1920*1080@25fps)
Extra Stream 1
(704*576@25fps),
Extra Stream 2
(1280*720@11fps)
NTSC:
Main stream
(2048*1536@20fps)
Extra Stream 1
(704*480@20fps),
Extra Stream 2
(1280*720@1fps)
Main Stream
(1920*1080@30fps)
Extra Stream 1
(704*480@30fps),
Extra Stream 2
(1280*720@1fps)
