Foreword General This manual introduces the functions, installation and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury.
Page 3
All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the manual. Please contact the customer service for the latest program and supplementary documentation. ...
Important Safeguards and Warnings Electrical safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
Page 5
It is recommended to use the device together with lightning arrester to improve lightning protection effect. It is recommended connect the grounding hole to the ground to enhance the reliability of the device. Do not touch the image sensor (CMOS) directly. Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol.
Regulatory Information FCC Information Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC conditions: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference.
Cable Cable type might vary with different devices, and the actual product shall prevail. Please waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ Manual. Figure 1-1 Cable list For more information about cable ports, see Table 1-1.
Network Configuration Device initialization and IP setting can be finished with the "ConfigTool" or in web interface. For more information, see the WEB Operation Manual. Device initialization is available on select models, and it is required at first use and after ...
Step 4 Select the devices that need initialization, and then click Initialize. The password setting interface is displayed. See Figure 2-2. Figure 2-2 Password setting interface Step 5 Set and confirm the password of the devices, and then enter a valid email address. Click Next.
Figure 2-3 Modify IP address interface Step 3 Select Static mode and enter start IP, subnet mask and gateway. IP addresses of multiple devices will be set to the same if you select Same IP. If DHCP server is available in the network, devices will automatically obtain IP addresses from DHCP server when you select DHCP.
Installation Packing List The tool required for the installation such as electric drill is not provided in the packing. The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. Dimension Following figures are for reference only, the actual product shall prevail.
Installing Device 3.3.1 Installation Method 3.3.2 Installing SD Card (Optional) SD card slot is available on select models. Press the reset button for 10 seconds to reset the device. 3.3.3 Attaching Device Make sure the mounting surface is strong enough to hold at least three times of the device weight.
Page 14
Cable going through the mounting surface Cable going through the side cable tray Installation 7...
3.3.4 Installing Waterproof Connector (Optional) This part is only needed when there is waterproof connector come with the device and the device is used outdoor. 3.3.5 Adjusting Lens Angle Installation 8...
