Dahua IPC-HFW2200R-VF User Manual page 8

Dahua HD IR Vari-Focal Fixed Network Camera User's Manual
Note:
The exact frame rate of extra stream 2 is decided by device max
capacity set, it is dynamic and adjustable during the range of max
capacity set.
H.264H: 40Kbps-8192Kbps; adjustable.
MJPEG: 40Kbps-16384Kbps; adjustable and bit rate is adjustable.
Video Bit Rate
Support customized setup. (The actual bit rate is subject to device
adjustable range)
Support mirror.
Video Flip
Supports flip, corridor mode function.
Snapshot Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask Supports max 4 privacy mask zones
ROI Supports max 4 ROI zones
Video Setup Support parameter setup such as bright, contrast and acutance.
Video
Channel title, time title, motion detect, tampering, overlay.
Information
Lens 2.8～12mm/F1.4(manual focus)
φ14 port, Lens is the default accessories
Lens Interface
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
Motion Detect
area threshold ranges from 0 to 100.
Sensitivity level 1-6, each level is corresponding to the tampered zone
percentage of the video
Video Tampering
Activation event: video storage, image snapshot, log, email function
and etc.
Video Priority Manual>Video detect>Schedule
Storage
Support NAS storage
Management
Wired Network 1-channel wired Ethernet port, 10/100 Base-T Ethernet
Standard,HTTP,TCP/IP,ARP,IGMP,ICMP,RTSP,RTP,UDP,RTCP,SMT
Network Protocol
P,FTP,DHCP,DNS,DDNS,PPPoE,UPnP,NTP,Bonjour,SNMP,Qos,802.
1x
Remote Monitor, system setup, file download, log information, maintenance ,
Operation upgrade and etc.
Platform
Interface PSIA, ONVIF
Protocol
Power DC12V power, PoE power supply
Power
4.5W MAX
Consumption
Working
-30℃~+60℃
Temperature
Working
≤95%
Humidify
Dimensions(mm) 72*80*212.8
Weight 650g
Installation Installation with the bracket.
(1280*720@1fps)
3
