Summary of Contents for Dahua IPC-HFW2231S-S-S2
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua IPC- HFW2231S-S-S2 o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza Bullet Network Camera Quick Start Guide V1.0.0 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
-
Page 2: Foreword
Foreword General This manual introduces the functions, installation and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury. - Page 3 updates might cause some differences between the actual product and the manual. Please contact the customer service for the latest program and supplementary documentation. There still might be deviation in technical data, functions and operations description, or errors in print. If there is any doubt or dispute, please refer to our final explanation. ...
-
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings Electrical safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1. - Page 5 protection effect. It is recommended connect the grounding hole to the ground to enhance the reliability of the device. Do not touch the image sensor (CMOS) directly. Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol. ...
-
Page 6: Regulatory Information
Regulatory Information FCC Information Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC conditions: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. -
Page 7: Table Of Contents
Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................III Regulatory Information ..........................V 1 Cable ............................... 1 2 Network Configuration.......................... 2 2.1 Initializing Device .......................... 2 2.2 Modifying Device IP Address ......................3 2.3 Logging in Web Interface ......................4 3 Installation .............................. -
Page 8: Cable
Cable Cable type might vary with different devices, and the actual product shall prevail. Please waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ Manual. Figure 1-1 Cable list For more information about cable ports, see Table 1-1. -
Page 9: Network Configuration
Network Configuration Device initialization and IP setting can be finished with the "ConfigTool" or in web interface. For more information, see the WEB Operation Manual. Device initialization is available on select models, and it is required at first use and after device is being reset. -
Page 10: Modifying Device Ip Address
All the devices found in the network segment are listed. Step 5 Select one or several devices which Status are Uninitialized, and then click Initialize. The Device initialization interface is displayed. Step 6 Select the devices that need initialization, and then click Initialize. The password setting interface is displayed. -
Page 11: Logging In Web Interface
After clicking Search setting, please make sure the username and password are the same as what you set during initialization, otherwise there will be "wrong password" notice. Step 2 Select the devices whose IP addresses need to be modified, and then click Modify IP. The Modify IP Address interface is displayed. - Page 12 Figure 2-4 Main interface Network Configuration 5...
-
Page 13: Installation
Installation 3.1 Packing List The tool required for the installation such as electric drill is not provided in the packing. The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. 3.2 Dimension Following figures are for reference only, the actual product shall prevail. -
Page 14: Installing Device
(Unit: mm [inch]) 3.3 Installing Device 3.3.1 Installation Method 3.3.2 Installing SD Card (Optional) SD card slot is available on select models. Installation 7... -
Page 15: Attaching Device
Press the reset button for 10 seconds to reset the device. 3.3.3 Attaching Device Make sure the mounting surface is strong enough to hold at least three times of the device weight. Cable going through the mounting surface Installation 8... -
Page 16: Installing Waterproof Connector (Optional)
Cable going through the side cable tray 3.3.4 Installing Waterproof Connector (Optional) This part is only needed when there is waterproof connector come with the device and the device is used outdoor. Installation 9... -
Page 17: Adjusting Lens Angle
3.3.5 Adjusting Lens Angle Installation 10... - Page 18 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. Address: No.1199, Bin'an Road, Binjiang District, Hangzhou, P.R. China Postcode: 310053 Tel: +86-571-87688883 Fax: +86-571-87688815 Email: overseas@dahuatech.com Website: www.dahuasecurity.com...
