Summary of Contents for Dahua IPC-HFW2531T-ZS-S2
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua IPC- HFW2531T-ZS-S2 o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza Bullet Network Camera Quick Start Guide ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.2...
-
Page 2: Foreword
Quick Start Guide Foreword General This manual introduces the installation, functions and operations of the network camera. Read carefully before using the device, and keep the manual safe for future reference. Safety Instructions The following signal words might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided,... - Page 3 Quick Start Guide ● There might be deviations in the description of the technical data, functions and operations, or errors in the print. If there is any doubt or dispute, we reserve the right of final explanation. ● Upgrade the reader software or try other mainstream reader software if the manual (in PDF format) cannot be opened.
-
Page 4: Important Safeguards And Warnings
Quick Start Guide Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, comply with the guidelines when using it. Transportation Requirements ●... - Page 5 Quick Start Guide against lightning. For outdoor scenarios, strictly comply with the lightning protection regulations. ● Ground the function earthing portion of the device to improve its reliability (certain models are not equipped with earthing holes). The device is a class I electrical appliance. Make sure that the power supply of the device is connected to a power socket with protective earthing.
- Page 6 Quick Start Guide ● Use the accessories suggested by the manufacturer. Installation and maintenance must be performed by qualified professionals. ● Do not directly touch the photosensitive CMOS. Use an air blower to clean the dust or dirt on the lens.
-
Page 7: Table Of Contents
Quick Start Guide Table of Contents Foreword ........................................I Important Safeguards and Warnings ............................III 1 Introduction ......................................1 1.1 Cable ........................................ 1 1.2 Connecting Alarm Input/Output ............................2 2 Network Configuration ..................................4 2.1 Initializing the Camera ................................4 2.2 Changing Device IP Address ..............................6 2.3 Logging in to Web Page ................................. -
Page 8: Introduction
Quick Start Guide 1 Introduction 1.1 Cable Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see FAQ manual. Figure 1-1 Cables Table 1-1 Cable information Port Name Description Inputs 12 VDC power supply, and supports power supply at the same time. -
Page 9: Connecting Alarm Input/Output
Quick Start Guide Table 1-2 Alarm information Port Port Name Description ALARM_IN Receives the switch signals of external alarm sources. ALARM_IN_GND Connect different alarm input devices to the same ALARM_IN_GND port. Alarm I/O ALARM_OUT Outputs alarm signals to alarm devices. When connecting to alarm device, only the ALARM_OUT_GND ALARM_OUT port and ALARM_OUT_GND port... - Page 10 Quick Start Guide than 12 V, please use an additional electric relay. Figure 1-3 Alarm output Step 3 Log in to web page, and configure alarm input and alarm output in alarm settings. ● The alarm input on the web page is corresponding to the alarm input end of the I/O port.
-
Page 11: Network Configuration
Quick Start Guide 2 Network Configuration Device initialization and IP setting can be finished with the ConfigTool or on web page. For more information, see web operation manual. ● Device initialization is available on select models, and it is required at first-time use and after device is reset. - Page 12 Quick Start Guide update the device, restart the device, and more. Click OK. Step 5 Select one or several cameras in uninitialized status, and then click Initialize. Step 6 Step 7 Select the devices to be initialized, and then click Initialize. ●...
-
Page 13: Changing Device Ip Address
Quick Start Guide Figure 2-3 Device initialization Step 9 Select Easy4ip or select Auto-check for updates as needed. If neither, leave them unselected. Step 10 Click OK to initialize the device. Click the success icon ( ) or the failure icon ( ) for the details. Step 11 Click Finish. -
Page 14: Logging In To Web Page
Quick Start Guide Figure 2-4 Modify IP address Step 3 Select Static mode, and then enter start IP, subnet mask, and gateway. ● IP addresses of multiple cameras will be set to the same if you select the Same IP checkbox. -
Page 15: Installation
Quick Start Guide 3 Installation 3.1 Packing List ● The tool required for the installation such as electric drill is not provided in the package. ● The operation manual and related tool information are contained in the disk or the QR code. Figure 3-1 Packing list 3.2 Dimensions Figure 3-2 Dimensions: Model A (mm [inch]) -
Page 16: Installing The Camera
Quick Start Guide 3.3 Installing the Camera 3.3.1 Installation Method Figure 3-4 Installation method 3.3.2 Installing SD Card ● SD card slot is available on select models. ● Disconnect the power before installing or removing the SD card. Press the reset button for 10 seconds to reset the device. Figure 3-5 Install SD card 3.3.3 Attaching the Camera Make sure that the mounting surface is strong enough to hold at least three times the weight of the... - Page 17 Quick Start Guide Figure 3-6 Cable going through the side cable tray Figure 3-7 Cable going through the mounting surface...
-
Page 18: Optional) Installing Waterproof Connector
Quick Start Guide 3.3.4 (Optional) Installing Waterproof Connector This part is needed only when a waterproof connector comes with the camera and the camera is used outdoors. Figure 3-8 Install waterproof connector 3.3.5 Adjusting Lens Angle Figure 3-9 Adjust lens angle... - Page 19 Quick Start Guide...
