- Page 1 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Version 1.0.0 Zhejiang Dahua Technology CO., LTD...
- Page 2 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Welcome Thank you for purchasing our network camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product!
-
Page 3: Important Safeguards And Warnings
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC or 24V AC in the IEC60950-1. - Page 4 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device.
-
Page 5: Table Of Contents
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Table of Contents General Introduction ........................1 Overview ........................1 Features ......................... 1 Specifications ........................ 2 1.3.1 Performance ......................2 Framework ........................... 6 Device External Cable ....................6 Framework and Dimension ..................6 Device Installation ........................ -
Page 6: General Introduction
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual 1 General Introduction 1.1 Overview This series network camera integrates the traditional camera and network video technology. It adopts video data collection, transmission together. It can connect to the network directly without any auxiliary device. -
Page 7: Specifications
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual to adjust the bright. Support digital WDR. Support video watermark function to avoid vicious video modification. Support dual bit streams, ACF. 1.3 Specifications 1.3.1 Performance Please refer to the following sheet for network camera performance specification. - Page 8 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual (1280*720@1fps) Note: The exact frame rate of extra stream 2 is decided by device max capacity set, it is dynamic and adjustable during the range of max capacity set. H.264H: 40Kbps-8192Kbps; adjustable.
- Page 9 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Model IPC-HFW2100R-Z IPC-HFW2200R-Z IPC-HFW2300R-Z Parameter Main Processor High performance DSP Embedded LINUX System Support real-time network monitoring, local record, and remote Resources operation at the same time. User Interface Remote operation interface such as WEB, DSS, PSS System Status Bit stream statistics, log, and software version.
- Page 10 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual MJPEG: 40Kbps-16384Kbps; adjustable and bit rate is adjustable. Support customized setup. (The actual bit rate is subject to device adjustable range) Support mirror. Video Flip Supports flip, corridor mode function. Snapshot Max 1f/s snapshot.
-
Page 11: Framework
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual 2 Framework 2.1 Device External Cable You can refer to the following figure for cable information. See Figure 2-1. Figure 2-1 Please refer to the following sheet for detailed information. Port... - Page 12 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Figure 2-2 Figure 2-3...
-
Page 13: Device Installation
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual 3 Device Installation Important Please make sure the installation surface can min support the 3X weight of the camera and the bracket. Step 1 Open accessories bag, take out installation position map and stick it to designated surface where you will install the device (wall or ceiling). - Page 14 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Figure 3-2 Step 6 Use inner hex screwdriver to loosen adjusting screw shown in Figure 2-2. Step 7 Adjust the device in all possible directions, and set its monitoring direction. Step 8 Use inner hex screwdriver to tighten the adjusting screws.
- Page 15 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Step 9 Screw out the pan head screw (shown in Figure 2-3) by cross head screwdriver and take off the lower cover. Step 10 Adjust the lens focus lever and set its monitoring direction more accurately by external focus.
-
Page 16: Quick Configuration Tool
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual 4 Quick Configuration Tool 4.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. - Page 17 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Figure 4-2 Search interface 2 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set.
-
Page 18: Web Operation
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual 5 Web Operation This series network camera products support the Web access and management via PC. Web includes several modules: Monitor channel preview, system configuration, alarm and etc. 5.1 Network Connection Please follow the steps listed below for network connection. - Page 19 Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Figure 5- 2 Web login After you successfully logged in, please install WEB plug-in unit. Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction.
-
Page 20: Faq
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual 6 FAQ The water leakage The unauthorized front or rear cap remove may result in water occurred. leakage. The glass front cap has sustained heavy push or strike. ... -
Page 21: Appendix Toxic Or Hazardous Materials Or Elements
Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component ○ ○ ○ ○...
