Page 1: Operating Instructions
Operating instructions Steam ironing system To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time. en - GB, IE M.-Nr. 10 522 010... -
Page 2: Caring For The Environment
/ recycling centre for electrical and electronic ap- pliances, or contact your dealer or Miele for advice. You are also respons- ible (by law, depending on country) for deleting any personal data that may be stored on the appliance being disposed of. -
Page 3: Table Of Contents
Contents Caring for the environment .................. 2 Warning and Safety instructions ................. 6 Guide to the appliance .................. 14 Transporting the appliance................. 17 Assembly...................... 18 Adjusting the height ....................19 Connection...................... 21 Insert the mains plug into the socket..............21 Removing the iron and the steam hose holder ............. - Page 4 Contents Active ironing board ....................37 Suction function .................... 37 Inflation function.................... 37 Automatic switch on/off ................... 37 Memory function .................... 38 Heated ironing surface .................. 38 Steamer ........................ 39 Connecting the steamer ..................39 Using the steamer ....................41 Brush attachment....................
- Page 5 Contents Cleaning the water filter..................59 Disconnect the power supply................ 59 Removing the water container ................. 59 Removing the water filter cover................ 59 Removing the sealing ring................ 60 Pull out water filter.................... 60 Cleaning the water filter.................. 61 Inserting the water filter.................. 61 Inserting the water container................
-
Page 6: Warning And Safety Instructions
The steam ironing system is intended for domestic use only, as described in these operating instructions. Any other use is not permitted. Miele cannot be held liable for dam- age resulting from incorrect or improper use or operation. ... - Page 7 Make sure that children under the age of eight cannot access the steam hose or the power cable, either during use or while the steam ironing system is cooling down. Miele recommends that only children over the age of 14 are al- lowed to operate the steam ironing system unsupervised. ...
- Page 8 If the connection cable is damaged it must be replaced with a special cable of the same type (available from Miele). For safety reas- ons this must only be fitted by a Miele authorised service technician or the Miele service department.
- Page 9 Faulty components must only be replaced by genuine Miele ori- ginal spare parts. Only when these parts are fitted can Miele guaran- tee the safety standards of the appliance.
- Page 10 Warning and Safety instructions The steam ironing system must be isolated from the electricity supply during installation, maintenance and repair work. The steam ironing system is only considered disconnected from the power sup- ply if: – the power plug of the steam ironing system is unplugged, or –...
- Page 11 Warning and Safety instructions Correct application Emitted steam, the iron soleplate together with the areas sur- rounding it on the iron, and the steamer jets are very hot. Danger of burning! Avoid direct contact. The steam ironing system is intended for domestic use only and is not designed for commercial purposes.
- Page 12 Warning and Safety instructions Always place the iron with its soleplate horizontally on the resting surface of the steam ironing system. Ensure the steam function is switched off and the soleplate does not protrude over the edges. Do not place the iron anywhere else as this presents a fire hazard. ...
- Page 13 Frozen water in the water container, steam generator or steam hose will cause damage to the appliance. Using accessories Accessory parts may only be fitted when expressly approved by Miele. If other parts are used, guarantee, warranty and/or product li- ability claims will be invalidated.
-
Page 14: Guide To The Appliance
Guide to the appliance a Ironing board i Ironing board X-frame b Iron with steam hose j Iron resting area c Steam hose holder k Mains connection cable d Handle l Bottom storage compartment For the power cable, the steamer*, e Water container the non-stick soleplate, and the holder for the power cable. - Page 15 Guide to the appliance Tower Tower (top view) with open storage com- partment (top) a Rotary dial for height adjustment d Steam hose holders and folding the appliance away e Control panel b Iron resting area f Steam hose holder c Steam connection g Iron with steam hose...
- Page 16 Guide to the appliance Some of the messages in the display are more than one line long. Touch the or button to read them in full. Control panel on tower h On/Off button Switches the steam ironing system on or off.
-
Page 17: Transporting The Appliance
Transporting the appliance The steam ironing system is fitted with two wheels. This allows the steam ironing system to be pulled across an even surface when folded up. Two people are required for carrying the steam ironing system up or down stairs. -
Page 18: Assembly
Assembly Take the steam ironing system to its set-up location. Use both hands to pull the ironing board upwards into a horizontal posi- tion until it audibly clicks into place Use one hand to pull the release on both sides of the tower. -
Page 19: Adjusting The Height
Assembly Adjusting the height The steam ironing system can be adjus- ted to your preferred working height. The maximum working height is 102 cm. When adjusting the height, ensure the power cable does not become trapped in the mechanism. The steam ironing system is now as- sembled. - Page 20 Assembly At the same time, pull the handle on the tower upwards with the other hand or press the handle down. Do not push down on the ironing board while adjusting the height! Always use the handle on the tower to do this.
-
Page 21: Connection
Connection Insert the mains plug into the socket. The steam ironing system is designed for connection to a properly installed earthed socket for AC 220-240 V, 50-60 Hz. Guide the power cable through the groove in the cover. Close the (bottom) storage compart- ment. -
Page 22: Removing The Iron And The Steam Hose Holder
Connection Removing the iron and the The steam ironing system is suitable steam hose holder for right- or left-handed people. Oper- ation is optimised for both sides. Connecting the steam hose Lift the lid of the steam connection. Open the lid of the (top) storage com- partment on the tower. - Page 23 Connection Do not place the iron in an up- right position! It can easily tip over or fall to the floor. Always place the iron onto the rest- ing surface with its soleplate down. If the iron remains on the resting surface for any length of time, the surface will become hot.
-
Page 24: Using For The First Time
Using for the first time Before using the steam ironing sys- Using the test strips tem for the first time, remove all packaging (e.g. the protective film from the tower). Determining water hardness In order for the steam ironing system to function properly and to display a mes- sage prompting you to descale it at the correct time, it is important to adjust the... -
Page 25: Before Using For The First Time
Using for the first time Language settings Before using for the first time The following steps must be carried out before using the appliance for the first time: deutsch Switch on the steam ironing system Use the or arrow buttons to select your preferred language setting. -
Page 26: Setting The Water Hardness
Using for the first time Setting the water hardness Level 7 Set water hardness... Use the or arrow buttons on the control panel to set the water hard- Before the water hardness can be set, ness level for your household. the display message ... -
Page 27: The Steam Ironing System Is Now Ready For Use
Using for the first time The steam ironing system is now ready for use This completes the settings for using the appliance for the first time. The message Initial set-up complete will ap- pear in the display. Confirm this mes- sage by pressing the OK button. -
Page 28: Switching On
Switching on Switch on the steam ironing Depending on the operating duration, system immediately after switching the steam ironing system on, the auto- matic rinse function can be started (see "Automatic rinsing") or you may start the descaling process (see "De- scaling"). -
Page 29: Filling The Water Container
Switching on Filling the water container Filling the water container If the water container is empty or not installed in the tower, the message Fill water cont. will appear in the dis- play. Removing the water container Open the screw cap at the rear of the water container by turning the cap anti-clockwise. -
Page 30: Steam Operation
Switching on Steam operation Water quality Use only fresh tap water. Water prepared using commercially available water filters may also be Ready for use used. For water hardness of more than 14°dH / 2.5 mmol/l you can use tap wa- After inserting the water container, wait ter mixed at a 1:1 ratio with distilled wa- until the steam ironing system is ready... -
Page 31: Selecting The Ironing Temperature
Switching on Selecting the ironing temperat- Temperature level is not hot enough for ironing with steam. If you use this temperature level, do not use the steam button. If you do, water will escape from the steam jets. Tip: Sort your laundry according to the heat sensitivity of the fabric;... - Page 32 Switching on Care label Ironing with steam for best Ironing without steam (on the garment) results (Material / Temperature setting) (Material / Temperature setting) With non-stick soleplate Minimum iron, synthetics Low temperature (see "Ironing with the non-stick soleplate") Minimum iron, synthetics, appli- qués, prints, flocking, etc.
-
Page 33: Cooldown Function
Switching on CoolDown function Do not leave the steam ironing system unattended with the iron or steamer connected! Always switch off at the wall socket Iron switched off and withdraw the plug before leaving the steam ironing system. Auto-Off function The iron will switch off automatically, if If the iron or the steamer is not used for... -
Page 34: Ironing
Power level button a Steam button d Inflation/suction button b Slider for constant steam provision Irons supplied with previous Miele steam ironing systems (B 1xxx/B 2xxx) c Suction function button cannot be used with this appliance. -
Page 35: Ironing With Steam
Ironing Ironing with steam The continuous emission of steam must have stopped before the iron is The steam system is ready for use put back on the resting surface! when Ready for use appears in the If the steam button was not unlocked display. -
Page 36: Ironing Without Steam
Ironing Attaching the non-stick soleplate Ironing without steam Place the tip of the iron inside the Remove the water container from the non-stick soleplate. steam ironing system if you want to iron without steam. The steam generator will not heat up and saves you energy. -
Page 37: Removing The Non-Stick Soleplate
Ironing Removing the non-stick soleplate Active ironing board Hold the iron by the handle. The steam ironing system uses a fan that sucks away the steam or uses the The non-stick soleplate is still inflation function to inflate the ironing very hot after ironing! board for optimum positioning while Avoid direct contact. -
Page 38: Memory Function
Ironing Memory function Fan control for the B 3826 / B 3847: The memory function saves the fan dir- ection and the power setting used last with your steam ironing system. When you use the appliance the next time, you do not need to set it again. Heated ironing surface When the iron is connected and the steam ironing system is switched on,... -
Page 39: Steamer
Steamer Connecting the steamer The B 3847 steam ironing system is equipped with a steamer in addition to You can also plug the steamer into the the iron. The steamer is available as steam connection of the ironing sys- an optional accessory for the B 3312 tem as an alternative to the iron. - Page 40 Steamer Attaching the steamer to the steam You can at any time plug the iron into connection the steam connection as an alternat- ive to the steamer. You do not need to switch off the steam ironing system to do this. After switching between the iron and the steamer, there is a short interval be- fore the steam is ready.
-
Page 41: Using The Steamer
Steamer Using short bursts of steam Using the steamer Briefly press button . Danger of burning due to hot Then release the button. steam! Never direct the steam or the steam Using continuous steam jets at people, animals or electrical ... -
Page 42: Brush Attachment
Steamer Brush attachment The steamer is equipped with a brush attachment which can be clipped on. The brush attachment helps to raise the fibres. You can hold the steamer directly onto the fabric while the brush at- tachment is in place. Always try it first on an inconspicu- ous part of the fabric. -
Page 43: Switching Off
Switching off To switch off the steam ironing sys- tem, press the button on the con- trol panel. The light in the button goes out. The steam ironing system is now switched off. The last selected fan set- Bottom storage compartment tings are saved and are available for the next time you switch on the appliance. -
Page 44: Dismantling
Dismantling Set the ironing board to its lowest working height To dismantle the steam ironing sys- tem, the ironing board must first be set to its lowest working height. Make sure you do not trap the power cable in the system. Ensure the residual wa- ter drawer is completely emptied, pushed in and locked in place. -
Page 45: Folding The Ironing Board
Dismantling Folding the ironing board Push the ironing board up by the tapered end until it is upright and Turn one of the two rotary dials as far locks into position on the tower. as it will go towards the position. The ironing board is now unlocked. -
Page 46: Disconnecting The Steam Hose
Dismantling Disconnecting the steam hose. Storing the iron Do not pull on the steam hose! The iron soleplate is still very hot Hold the plug at the end of the steam after use! hose. The plug may still be warm im- Avoid direct contact. -
Page 47: Emptying The Water Container
Dismantling Emptying the water container Storing the steam ironing sys- Empty the water container if the steam ironing system is not going to be used for a long period of time. Take the steam ironing system to its storage place. Do not store the steam ironing sys- ... -
Page 48: Cleaning And Care
Cleaning and care Emptying the residual water drawer Automatic rinsing After the rinsing process has com- The automatic rinse function clears pleted, the residual water drawer must the steam generator of mineral depos- be emptied. The message Empty its from the evaporated water. drawer will appear in the display on the After approx. -
Page 49: Descaling
"FashionMaster descaling tablets". they are dirty or damp. These have been specially de- veloped for use with Miele appli- Slide the residual water drawer back ances to optimise the descaling pro- into the tower until it clicks into place. -
Page 50: Descaling Warning
Cleaning and care Descaling warning additional 60 minutes. The steam iron- ing system can be left unattended for Descale soon will appear in the dis- the rest of the time. play the next time you switch the steam ironing system on if there are only about Tip: To optimise the descaling process, 2 hours of ironing available before the start the procedure while the system is... -
Page 51: Starting The Descaling Process Early
Cleaning and care Starting the descaling process early Descaling process The following display messages will guide you through the entire descaling process. Only proceed with the re- Ready for use quired action if you are prompted to do so by the appropriate message in the display. - Page 52 Cleaning and care Fill water container to the mark Add descaler Turn the screw cap at the back of the water container anti-clockwise and remove the cap. Hold the water container by its handle. Pull the handle downwards. Level mark on the water container The water container is released from the ...
- Page 53 Cleaning and care Fit water container Put the water container back into the tower. Add descaler After about 10 minutes (the time it takes for the descaling tablet to dissolve), the descaling process begins automatically. Press the OK button to display the Messages in the display will tell you next step.
- Page 54 Cleaning and care Empty drawer Pre-rinse This message may be displayed after If the steam ironing system is still hot inserting the water container with the from the previous use, the cool down descaling tablet. If you do not see this phase will start first.
- Page 55 Cleaning and care Rinse water container and fill to Empty drawer the mark Remove the residual water drawer Remove the water container from the from the tower. tower. The message Fit drawer will appear As long as the water container is not in- in the display.
- Page 56 Cleaning and care Empty drawer Descale Remove the residual water drawer After an activation time of approx. 1 hour, the descaling solution is drained and empty it. from the steam generator into the resid- The message Fit drawer is now ual water drawer.
-
Page 57: Cleaning The Housing
Cleaning and care To avoid damaging the surface, do Cleaning the housing not use the following for cleaning: Before cleaning the housing, – abrasive cleaning agents, (e.g. switch off at the socket and with- powder cleaners, cream cleaners, draw the plug. -
Page 58: Cleaning Or Replacing The Ironing Board Cover
Cleaning and care Wash and dry the ironing board cover Cleaning or replacing the iron- according to the care label or replace ing board cover the cover if it is damaged. If the ironing board cover is soiled, you Never use the steam ironing system can wash and dry it. -
Page 59: Cleaning The Water Filter
Cleaning and care Removing the water filter cover Cleaning the water filter The water filter prevents foreign ob- jects in the water from entering the steam ironing system and causing damage. The water filter can be cleaned if it is dirty or clogged. -
Page 60: Removing The Sealing Ring
Cleaning and care Removing the sealing ring Pull out water filter Use the hook on the water filter cover Push the round tool on the water filter to pull the sealing ring up and out of cover onto the water filter from the right-hand socket. -
Page 61: Cleaning The Water Filter
Cleaning and care Cleaning the water filter Inserting the water filter Position the water filter with the small seal facing downwards. Press the water filter fully into the right-hand socket. Then replace the seal in the right- hand socket. -
Page 62: Inserting The Water Container
The water filter must be replaced if it is worn or damaged. Replacement filters are available from your Miele retailer or from the Miele Spare Parts Department. Use a cross-head screwdriver to tighten the screw. -
Page 63: Optional Accessories
Miele online shop (www.miele- shop.com), Miele Spare Parts Depart- Ironing board cover ment or your local Miele retailer. Miele ironing board covers are very dur- able and highly absorbent. The separate needle felt underlay is steam-permeable and pleasantly cushioned. The Miele ironing board covers can be used for any Miele steam ironing sys- tem. -
Page 64: Steamer
Optional accessories Steamer Care products The steamer makes ironing hanging tex- The Miele care product range has been tiles easier, e.g. dresses and jackets. It developed specially to clean your appli- comes with a removable brush attach- ance thoroughly and gently. -
Page 65: Problem Solving Guide
Problem solving guide The majority of malfunctions and faults that occur during the daily routine can be put right without contacting the Service Department, saving you time and money. The following information will assist you in identifying a malfunction or fault and rectifying it yourself. -
Page 66: Troubleshooting
Problem solving guide Troubleshooting Problem Cause and remedy The steam ironing sys- The steam ironing system does not have any power. tem cannot be switched Check that – the plug is inserted into the wall socket and that the socket is switched on. –... - Page 67 Then let go of the rotary dial on the side and sub- sequently release the unlocking button on the tower. Now the ironing board can either be folded away or brought into its working position. If the ironing board still will not lock into place, contact Miele Service.
- Page 68 Rectify the indicated malfunction and proceed as described in the following pages (see "Display messages"). The steam ironing system is damaged. Contact Miele Service. The ironing board is not Steam has not been used for a while. heated.
- Page 69 Put the dry ironing board cover back on (see "Cleaning or replacing the ironing board cover"). If the ironing board gets damp again, contact Miele Service. Water is leaking from The frequent removal and replacement of the water...
- Page 70 Rectify the indicated malfunction and proceed as described in the following pages (see "Display messages"). If there is still no steam, contact Miele Service. When using the steam The selected temperature level on the iron is too low. button on the iron, ...
-
Page 71: Display Messages
Press the button to switch the steam ironing system back on again. The steam ironing system will attempt to correct the fault itself. If the fault message continues to be displayed, switch off at at the wall socket and withdraw the plug. Contact Miele Service. - Page 72 Push the residual water drawer back in the tower until it clicks into place. There is a fault. If the fault message continues to be displayed, contact Miele Service. Message in the display: There is a fault. ...
- Page 73 The steam ironing system is now ready for operation and will continue to operate from the point reached before the fault was registered. There is a fault. If the fault message continues to be displayed, contact Miele Service.
- Page 74 Press the button to switch the steam ironing system off and then back on again. F45: LNG The steam ironing system will try and rectify the fault itself. If the fault message continues to be displayed, con- tact Miele Service.
-
Page 75: Service
Please note contact Miele. See end of this booklet that telephone calls may be monitored for contact details. and recorded for training purposes. -
Page 76: Electrical Connection Uk
Electrical connection UK Before you connect the steam iron- Do not use a multi-socket unit or an ing system, you must check the con- extension cable to connect the nection data (voltage and frequency) steam ironing system to the power on the data plate and compare it with supply. -
Page 77: Technical Data
Technical data Dismantled dimensions (H x W x D) 1280x470x370 mm Assembled dimensions (H x W x D) 970x470x1480 mm Weight 29 kg Voltage See data plate Total connected load See data plate Fuse rating ≥ 10 A Steam pressure for B 3312 3.5 bar Steam pressure for B 3826 and B 3847 4.0 bar... - Page 79 Tel. +971 4 3044 999 Tel: (01) 461 07 10, Fax: (01) 461 07 97 Fax. +971 4 3418 852 E-Mail: info@miele.ie, Internet: www.miele.ie 800-MIELE (64353) Manufacturer: Miele & Cie. KG E-Mail: info@miele.ae Website: www.miele.ae Carl-Miele-Straße 29, 33332 Gütersloh, Germany...
