Troubleshooting - Bosch AFS 23-37 Original Instructions Manual

Hide thumbs

Advertisement

Table of Contents
OBJ_BUCH-2432-004.book Page 18 Thursday, September 29, 2016 12:04 PM
18 | English
Working Advice
Usage application area
Clearing brambles/brush
Cutting saplings

Troubleshooting

Problem
Possible Cause
Machine fails to operate
Power turned off
Mains socket faulty
Extension cable damaged
Fuse faulty/blown
Thermal cut out
Machine functions
Extension cable damaged
intermittently
Internal wiring of machine damaged
Machine does not cut
Cutting blade/line damaged
Increased vibration
Cutting blade damaged
Cutting line broken
Debris build up on cutting head
Blade nut loose
Cutting blade incorrectly fitted
Machine leaves ragged fin-
Grass too high/dense
ish and/or labours
Cutting blade blunt
Cutting blade obstructed
Debris build up on cutting head
Nut cannot be removed to
Damaged thread on nut/shaft
release cutting blade
Locking pin not located correctly
F 016 L81 507 | (29.9.16)
Usage application area
Trimming/thinning
Cutting system
Clearing weeds
blade
Cutting long grass
blade
Clearing nettles
Cutting system
line
line/blade
line
line/blade
Corrective Action
Turn power on
Use another socket
Inspect cable, replace if damaged
Replace fuse
Allow tool to cool and try again
Inspect cable, replace if damaged
Contact Service Agent
Contact Service Agent
Replace the blade/line (always wear protective
gloves)
Replace the blade (always wear protective
gloves)
Replace line
Clean cutting head and remove debris
Tighten nut bolt to 20 Nm ensuring the blade,
nut shield and dome washer are all present and
central (always wear protective gloves)
Remove cutting blade and refit in a fully central
position. Use guide rings on the blade to ensure
correct central alignment
Grass too high: Cut in stages
Grass too dense: Reduce rate of cutting every
time
Flip/replace blade
Check underneath the machine and clear out as
necessary (always wear protective gloves)
Clean cutting head and remove debris
Lubricate shaft to aid removal
Reinsert locking pin and apply light pressure
whilst rotating shaft
