Sapling SALG Series Installation Manual page 13

Wall Mount Installation - Round Standard ABS Clock
5) Place the two wall anchors into the holes, then
screw the two #10 self-tapping screws through the
bracket and into the wall anchors.
7) Slide the long, protruding part of the mounting
bracket into the clock case keyhole.
5 6
7 8
The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
6) First remove the gearbox pin, then attach the
power connector to the port on the movement.
1
2
8) Align the peg on the top portion of the
mounting bracket with the hole on top of the
clock case. Slide the peg through the hole. Use the
bracket securing nut to secure the peg in place.
P. (+1) 215.322.6063
F. (+1) 215.322.8498
www.sapling-inc.com
1
2
13
