Sapling SALG Series Installation Manual page 105

Double Mount Installation - Square Clock - Battery Powered
11) Attach the base of the pole to the mounting plate, so that the lip is on the top of the base, and the
holes for the screws are on the bottom of the base. Hang the base on the mounting plate, attach the
wires from the bottom of the pole to the wires in the gang box, then screw the other side of the base
onto the mounting plate using the two black screws you set aside before.
2
12 13
12) Remove the back covers from the battery packs
by pulling the two latches away to either side and
sliding the cover out.
1
WALL
The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
11
2
1
CEILING
13) First remove the gearbox pins, then insert
the batteries into the clock. If the clock is within
range of a powered transmitter, the hands should
begin to move within a minute.
1
P. (+1) 215.322.6063
F. (+1) 215.322.8498
www.sapling-inc.com
2
105
