CONTROL PANEL DESCRIPTION

8
KEY
1 TFT display
2 Group display
3 Coffee pour containers
4 USB port
5 Rotary switch
6 Wash button
44
1
7 6 5
7 Cup warmer ON/OFF button
8 Machine ON/OFF button
4
2 3
Fig. 2
