UDP Functionality

Overview

The
UDP
broadcasts the I/O channel status in a UDP message.
You can configure up to four sets of IP address entries (each entry consisting of a start and end IP
address range) to broadcast I/O status data. The data depends on the I/O model (Analog, Digital,
Serial Signals) and contains information for all channels.

Field Descriptions

Configure the following parameters:
Enable UDP
Broadcast of I/O
Status
Broadcast Interval Enter the interval, in seconds, for UDP broadcasts of I/O channel status (data).
Settings Button
tab configures the I/O UDP broadcast settings. The I/O UDP broadcast feature periodically
Enables/disables UDP broadcast of I/O channel status (data).
Default: Disabled
Range: 1-9999
Default: 30 seconds
Click this button to configure the UDP IP addresses that will receive the I/O
status information.
See I/O UDP Settings on page 134
Settings window.
for field descriptions for the I/O UDP
Settings
