Timing Characteristics

All signals beginning with 'X' are 'low active'. All timing values are based on
the capacitive loads specified in the table above.
10.7.1 System Bus Interface
C lock
C lock frequency is 48 MHz. Distortion of the clock signal is permissible up
to a ratio of 30:70 at the threshold levels 0.9 V and 2.1 V.
Parameter
Clock period
Clock high time
Clock low time
Clock rise time
Clock fall time
Figure 10-7: Clock Timing
Note:
For 3.3V operation the VPC3+C is equipped with 5V tolerant inputs except
for the clock pin CLK. When using 3.3V supply voltage the clock input needs
to be 3.3V level.
Interrupt:
After acknowledging an interrupt with EOI, the interrupt output of the
VPC3+C is deactivated for at least 1 us or 1 ms depending on the bit
EOI_Time_Base in Mode Register 0.
Parameter
Interrupt inactive time EOI_Timebase = '0'
Interrupt inactive time EOI_Timebase = '1'
Figure 10-8: End-of-Interrupt Timing
Reset:
VPC3+C requires a minimum reset phase of 100 ns at power-on.
