Next_Dout_Buffer_Cmd. If the user is supposed to enlarge the output data
buffer after the Chk_Cfg telegram, the user must delete this deviation in the
'N' buffer himself (possible only during the start-up phase in the WAIT-CFG
state).
If 'Diag.Sync_Mode = 1', the 'D' buffer is filled but not exchanged with the
Data_Exchange telegram. It is exchanged at the next Sync or Unsync
command sent by Global_Control telegram.
Address
bit 7-6
bit 5-4
bit 3-2
bit 1-0
Figure 6-12: Dout-Buffer Management
When reading the Next_Dout_Buffer_Cmd the user gets the information
which buffer ('U' buffer) belongs to the user after the change, or whether a
change has taken place at all.
VPC3+C User Manual
Copyright © profichip GmbH 2004-2006
7 6
0AH F
Dout_Buffer_SM, Address 0AH:
F: Assignment of the F-Buffer
00 = Nil
01 = Dout_Buf_Ptr1
10 = Dout_Buf_Ptr2
11 = Dout_Buf_Ptr3
U: Assignment of the U-Buffer
00 = Nil
01 = Dout_Buf_Ptr1
10 = Dout_Buf_Ptr2
11 = Dout_Buf_Ptr3
N: Assignment of the N-Buffer
00 = Nil
01 = Dout_Buf_Ptr1
10 = Dout_Buf_Ptr2
11 = Dout_Buf_Ptr3
D: Assignment of the D-Buffer
00 = Nil
01 = Dout_Buf_Ptr1
10 = Dout_Buf_Ptr2
11 = Dout_Buf_Ptr3
Revision 1.03
PROFIBUS DP Interface 6
Bit Position
5 4 3 2
U N
Designation
1 0
D Dout_Buffer_SM
