Lx-100 Rf Power/Load Center; Filter Pump And Pool Cleaner Time Clocks - Pentair EasyTouch Pool/Spa Control System LX-100EZ Installation And Owner's Manual

Located in close proximity to your pool equipment, the LX-100 RF Power/Load Center houses mechanical time clocks
for your filter pump and pool cleaner (if applicable), and manual switches for your Pool Serviceperson.

FILTER PUMP and POOL CLEANER Time Clocks

Check with your Pool Builder or Service Company as to the amount of time required to provide efficient filtration and
cleaning of your pool.
To set the correct time of day, rotate the Dial(s) in a clockwise direction until the hours and minutes line up with the
white arrow at eight o'clock position on clock face.
Pay particular attention to the AM and PM sections of the Dial(s).
To program the daily filtration or cleaning cycle(s), depress the desired number of sections around the perimeter
of the Dial(s) by pushing towards the center. For each section depressed, the equipment will operate for 15 minutes.
A built-in protection circuit automatically activates the filter pump whenever the pool cleaner is running, even
if the FILTER PUMP Time Clock is not programmed on. This safeguards against possible damage to the pool
cleaner pump when there is no water circulation.
Rev. F 3-26-04

LX-100 RF POWER/LOAD CENTER

NOTE
23 P/N 520050
