INDOOR CONTROLLER
Installed in a convenient location inside your house, the Controller gives you fingertip control of all the equipment
associated with your swimming pool and spa.
Equipment PUSH-BUTTONS #S, #1, #2 and #3
Four Push-buttons are provided for activating the various pieces of equipment. Your Pool Builder has custom-labeled
each Push-button for your specific application.
Equipment Status Indicators
Status Lights are located above each Push-button. The presence of a light indicates that the equipment is running.
The absence of a light indicates that equipment is turned off.
TEMPERATURE Display
A digital display indicates water temperature. Spa temperature is displayed during spa circulation, and pool
temperature is displayed during pool circulation.
Note
The filter pump must be running to provide accurate temperature display.
Using Your Spa
To turn your spa on, simply press Push-button #S.
The motorized valves will rotate to spa circulation, the filter pump will turn on and the heater will fire.
The TEMPERATURE Display will let you know when the spa is ready for use.
Rev. F 3-26-04
27
P/N 520050
