Summary of Contents for Riva RC4602HD-6416
-
Page 1: Installation Guide
RC4602HD-6416 Installation Guide www.rivatech.de... -
Page 2: Information To User
INFORMATION TO USER CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). CONTACT QUALIFIED SERVICE PERSONNEL FOR INTERNAL PARTS. This symbol is intended to alert the user the presence of un- insulated “dangerous voltage”... -
Page 3: Table Of Contents
Table of Contents 1. FEATURES ......................4 2. PACKAGE CONTENTS ..................5 3. PART NAMES ..........Fehler! Textmarke nicht definiert. 4. INSTALLATION ....................8 4.1. Setting the Lens Position ..............9 4.3. Setting the Image Attribute ............. 9 5. CONNECTIONS....................10 6. -
Page 4: Features
1. FEATURES Camera Full HD outdoor high-speed dome IP camera High quality compression in real time streaming 1/3” High Quality CMOS Image Sensor Optical 20X, Digital 8X zoom True Day / Night (ICR) Stealth Spin® (World’s most silent speed dome) ... -
Page 5: Package Contents
Built-in Video Content Analysis Internal fan/heater SDK (Software Development Kit) provided IP66 (Outdoor) Certified 255 Dome positions * When VCA is activated, frame rate is limit to max15fps@1080p. Limitations are based on V.1.5.0 firmware release and could be changed without notice. 2. -
Page 6: Part Names
3. PART NAMES PCB Top View ⑦ ⑥ ⑤ ④ ③ ② ① Main Camera Top View ⑧ ⑨ * Models and their appearance are subject to change without any prior notice. www.rivatech.de... - Page 7 1. 3-Pin terminal block connector 2. Video Out For power connection (AC, FG, AC) CVBS : 1.0 Vp-p / 75Ω composite3.5 3. Audio microphone stereo jack 4. Audio speaker stereo jack connector connector Connector for 3.5mm audio jack plug. Connector for 3.5mm audio jack plug. 5.
-
Page 8: Installation
3. INSTALLATION Secure three screws camera’s main body as three unit holders with metal rings attached in the end. 2) Connect all necessary cables to a PCB board in a cover shield before conjoining the shield to a camera’s main body. 3) Under the PCB board has a 32-pin connector which... -
Page 9: Setting The Lens Position
Setting the Lens Position The device is 360° rotating camera and fully controlled by web user interface. Once the unit’s installation is complete and connected properly, please refer to RIVA Web Interface Manual Full HD Series for the device’s camera configuration instructions. -
Page 10: Connections
4. CONNECTIONS Top View ④ ② ③ ① ⑤ * Models and their appearance are subject to change without any prior notice. 1. Audio Mic in and Line out (3.5mm) Support PCM8/16, G.711 a-law, and u-law compression formats. 2. Sensor (DI) connection The camera provides 4 channel D/I. - Page 11 3. Alarm (DO) connection The device supports two digital outputs. The max relay capacity is 30VDC/2A, 125VAC/0.5A, and 250VAC/0.25A. Name Descriptions Normal Close 1 COM1 Common 1 Normal Open 1 Normal Close 2 COM2 Common 2 Normal Open 2 4. LAN connector Use 10/100 Base-T Ethernet cable to connect to a network.
- Page 12 6. Micro SD slot Located on top of main device, next to 32-pin socket, a user must push the upper cover as inscribed arrow direction next to “OPEN” to open the case. Slide the micro SD card into the opened cover with its gold contacts facing down. Once the card is inserted, close down the upper cover, and push the cover as inscribed arrow direction next to “LOCK”...
-
Page 13: Configuration
5. CONFIGURATION 5.1.Set up network environment The default IP address of the device is 192.168.XXX.XXX. Users can identify the IP address of the device from converting the MAC address’s hexadecimal numbers, which is attached to the device. Be sure that the device and PC are on a same area network before running the installation. -
Page 14: Custom Ip Environment
5.1.2. Custom IP Environment IPAdminTool and the manual can download from homepage. www.rivatech.de IPAdminTool is a management tool, which automatically scans all of the network products for users to perform administrative tasks, which includes network configurations, firmware update, device reboot, and device organizations. To modify the device’s default IP address for customized network area;... -
Page 15: View Video On Web Page
3. In the IP Setup’s window, information under ‘Local Network information’ displays the user/PC’s network area information. Those information need to be incorporated to the IP Address, Subnet Mask, Gateway, and DNS boxes, except the last 2 sets of IP Address, which are to be the unique numbers for the device. Refer to the image above for the setting 4. - Page 16 2. When Setup installation pop-up window appears, click install to proceed with rest of installations. Depends on system OS and Internet Explorer version, Installation experience may differ from one another. Figures described above Note are from Windows 7, Internet Explorer 9 environment. www.rivatech.de...
-
Page 17: View Video Using Ipadmin Tool
5.2.2. View video using IPAdmin Tool IPAdminTool automatically searches all activated network encoders and IP cameras and shows the product name, IP address, MAC address and etc. IPAdminTool can download from homepage. www.rivatech.de 1. From the IPAdminTool’s product list, select the device by highlighting it. 2. -
Page 18: Reset
5.3. Reset Perform the following procedures to reset your device: 1. Press the Reset button for 2 seconds. 2. Wait for the system to reboot. Reset Button Location 5.4. Factory Default Resetting the device back to the factory default will initialize all parameters including the IP address back to the factory defaults. -
Page 19: Appendix (A): Specifications
APPENDIX (A): SPECIFICATIONS Summary Camera Module Image Sensor 1/3” 1080p CMOS Effective 1920x1080 CMOS Pixels Scanning Progressive scanning system Resolution 1920 x 1080 ELECTRIC Min. Color: 1.5Lux(50 IRE) / 0.02Lux(Sens-up) Illumination B/W : 0.1Lux(50 IRE) / 0.001Lux(Sens-up) Type DC auto iris Focal Length 4.45 ~ 89mm (Optical x20) Aperture... -
Page 20: Electrical Characteristics
Power over Ethernet Supported TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP, RTP/TCP, Protocol SNTP, mDNS, UPnP, SMTP, IGMP, DHCP, DDNS, SSL v2/v3, IEEE 802.1X, SSH, SNMP v2/v3 Supported (MicroSD/SDHC) SD Slot ※ Micro SD Card not included * When VCA is activated, frame rate is limited to max 15fps@1080p. Limitation is based on V.1.4.0 firmware release and could be changed without notice. -
Page 21: Appendix (B): Power Over Ethernet
APPENDIX (B): POWER OVER ETHERNET The Power over Ethernet (PoE) is designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3af Power-over- Ethernet (PoE) standard. IEEE 802.3af allows for two power options for Category 5 cables. The IEEE 802.3af-2003 standard allows up to 15.4 W of power the device. -
Page 22: Power Comparison
Power Comparison Property 802.3af 802.3at Available Power 12.95 W 25.50 W Max. Power by PSE 15.40 W 34.20 W Max. Current 350 mA 600 mA Supported Cable Category 3 and 5 Category 5 Disconnecting PSE or PoE does not reboot the device as long as a power adaptor is connected. -
Page 23: Appendix (C): Dimensions
APPENDIX (C): DIMENSIONS (Unit: mm) www.rivatech.de... -
Page 24: Appendix (D): Hexadecimal-Decimal Conversion Table
APPENDIX (D): HEXADECIMAL- DECIMAL CONVERSION TABLE Refer to the following table when you convert the MAC address of your device to IP address. www.rivatech.de... -
Page 25: Revision History
REVISION HISTORY MAN# DATE(M/D/Y) Comments 01A.00 12/06/2012 First release version www.rivatech.de...
