- Page 1 D E S I G N E R S E R I E S MANUAL INTELLIVENT ®...
-
Page 2: Specifications
Thank you for choosing this product from Manrose. Before installing and using the fan, read through these instructions. Keep them safe for reference in future. SPECIFICATIONS IMPORTANT All electrical work must be carried out in accordance with local and national electrical codes as applicable. We strongly recommend that this light fitting is installed by a registered electrician. -
Page 3: Table Of Contents
CONTENTS Description of functions Installation guide 1 Contents 2 Installation 3 Connection 4 Installation options 5 Connecting a pull cord switch 6 Factory setting 7 Setting functions Advanced functions • Setting humidity sensitivity mode • Pause function with momentary switch LED indicators Maintenance Warranty... -
Page 4: Description Of Functions
DESCRIPTION OF FUNCTIONS • Automatic moisture detection system Intellivent is equipped with fully automatic humidity control. • Timer Selectable delay time – 5, 15 or 30 minutes. • Speed control The intergrated speed control allows you to adjust the noise level and capacity to meet your needs. •... -
Page 5: Installation Guide
INSTALLATION GUIDE 1 Contents The packaging should contain the following: • Fan • 2 adapters, 1 x Ø98 mm and 1 x Ø118 mm • Manual • Accessory bag with 4 screws and plugs, a pull cord with toggle, and insulation for the standard cable type (FK). 2 Installation The fan can be installed on a wall or on a ceiling. - Page 6 3 Wiring • All electrical work must be carried out by a registered electrician. • The fan is double insulated and must not be earthed. • The fan is fitted with a multi-pole switch and does not require a pre-wired external switch. 1 Push the multi-pole switch up to position 0 –...
-
Page 7: Installation Options
4 Installation options The fan can be installed in any of three ways depending on the desired function, as detailed below: 1 Humidity control only, see diagram 1 The fan is connected to constant phase (L) and neutral (N) for automatic humidity control. The timer can be activated manually by installing a pull cord and pulling it (see page 8). -
Page 8: Connecting A Pull Cord Switch
Use an ordinary round file to create a smooth cut-out at a suitable place in the front cover. Do NOT use pliers or similar tools, as these may cause the cover to crack. 5 Connecting the pull cord switch A pull cord can be installed for activating the timer manually or for pausing the fan. -
Page 9: Factory Setting
6 Factory setting SPEED • timer – 5 minutes • humidity speed – silent (70% of max.) TIMER • timer speed – 70% of max. CONSTANT TIMER • constant operation – off HUMIDITY Restore factory settings SILENT Hold the S-button in for a minimum of 5 seconds. -
Page 10: Advanced Functions
ADVANCED FUNCTIONS Selecting humidity sensitivity mode Bathroom climates may vary depending on a number of factors: room size, the presence of any natural draught ventilation, temperature, etc. These factors may affect the fan humidity response, causing it to start too quickly or too slowly. - Page 11 Pause function using momentary switch You can pause the fan for one hour by engaging an exter- nal momentary switch. This can be connected as shown in diagram 3 on page 7. With this function selected, you will be unable to use the delayed start via switched live (lighting) function connected to SL Activation...
-
Page 12: Led Indicators
LED INDICATORS LED – what is the fan doing? Intellivent is equipped with a three-colour LED indicator: yellow, blue and purple. These three colours tell the user what the fan is doing and which function is currently controlling the motor. •... -
Page 13: Maintenance
MAINTENANCE Clean the fan at least twice a year, or as required. Disconnect the power supply to the fan by pushing the multi-pole switch up to position O - OFF. The fan is fitted with a removable propeller. Press in the centre using your thumb, grip the fan wings and pull off the propeller. - Page 14 Never submerge the fan in water, as there is a risk that this could damage the fan's motor. After cleaning, swing the motor mount ring back into position and lock it by securing the snap-in catch. Switch the multi-pole switch back on by moving the switch down to position 1 –...
-
Page 15: Warranty
WARRANTY We provide a 5 year warranty against manufacturing defects. For the warranty to be valid, proof of purchase is required and the fan: - must be assembled and installed in accordance with the installation guide in this manual - must have been maintained according to the maintenance instructions in this manual - must be installed in a normal residential environment - must be connected to a voltage of 240 V AC ~ 50Hz... -
Page 16: Accessories
ACCESSORIES There are a number of accessories available for Intellivent to help you, as a user, install the product as smoothly as possi- ble. Please refer to www.simx.co.nz, keyword "Intellivent", for all the latest accessories for your Intellivent. Below are some examples of accessories. Pipes for sizes 100 and 125... -
Page 17: Technical Data
TECHNICAL DATA Maximum capacity 134 m³/h Sound pressure level 3 m (Silent mode) 21 dB(A) Power consumption 2,1 - 5,5 W Max Watts Mounting dimensions in wall 0 - 30 mm Holes 105 -130 mm Material ABS plastic Protection rating IP44 Insulation class Voltage... -
Page 18: Troubleshooting Guide
TROUBLESHOOTING GUIDE The fan runs non-stop The blue LED is on constantly (If the fan has been running non-stop for at least 24 hours) Check that it is working by opening the bathroom door and leaving it open for at least half an hour to equalise humidity levels. - Page 22 is proudly distributed by Simx Limited PO Box 14 347, Panmure, Auckland, NZ. Technical Support (09) 259 1662 | e: sales@simx.co.nz www.simx.co.nz We reserve the right to change specification without prior warning PUB1337 iss01 08/15...
