PLEASE READ THESE INSTRUCTIONS IN CONJUNCTION WITH THE ILLUSTRATIONS.
220-240V~50Hz
Installation and Wiring Instructions
Manrose Quiet Fan X5 S
Manrose Quiet Fan X5 T
Manrose Quiet Fan X5 HT
Manrose Quiet Fan X5 PIR
PLEASE SAVE THESE INSTRUCTIONS.
IPX5
Advertisement
Table of Contents
Related Manuals for Manrose Quiet Fan Series
Summary of Contents for Manrose Quiet Fan Series
- Page 1 Installation and Wiring Instructions Quiet Fan Range QF100SX5OP Manrose Quiet Fan X5 S QF100TX5OP Manrose Quiet Fan X5 T QF100HTX5OP Manrose Quiet Fan X5 HT QF100PIRX5OP Manrose Quiet Fan X5 PIR PLEASE READ THESE INSTRUCTIONS IN CONJUNCTION WITH THE ILLUSTRATIONS.
- Page 2 E. The Fan should only be used in conjunction with the appropriate Manrose products. F. The Fan should only be used in conjunction with fixed wiring. G. When the Fan is used to remove air from a room containing a fuel- burning appliance, ensure that the air replacement is adequate for both the fan and the fuel-burning appliance.
- Page 3 L. Stationary appliances not fitted with means for disconnection from the supply mains having a contact separation in all poles that provide full disconnection under over voltage category III, the instructions state that means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. M.
- Page 4 WIRING WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING THE INSTALLATION / OR MAINTENANCE IMPORTANT The fan should only be used in conjunction with fixed wiring. The cross - sectional area of supply cord used should be ranged from 0.75-1.5mm ...
- Page 5 SERVICING AND MAINTENANCE WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING MAINTENANCE. 1. At intervals appropriate to the installation, the fan should be inspected and cleaned to ensure there is no build-up of dirt or other deposits. 2.
- Page 6 Fig.3: QF100TX5OP, QF100HTX5OP & QF100PIRX5OP 220-240V ~ 50Hz 3 AMP Fig. 5 : PIR TIMER Timer Adjustment Timer Adjustment To REDUCE the operating time, use a small screwdriver to turn the adjuster ANTI-CLOCKWISE. To remove the grille, push both clips on each To INCREASE the operating time, use a small side (1) screwdriver to turn the adjuster CLOCKWISE.
- Page 7 Fig.7: QF100HTX5OP Humidity Adjustment To INCREASE SET POINT, turn the adjuster CLOCKWISE. This makes the controller LESS sensitive. To REDUCE SET POINT, turn the adjuster ANTI-CLOCKWISE. This makes the controller MORE sensitive. Humidity Adjustment Timer Adjustment To REDUCE the operating time, use a small screwdriver to turn the adjuster ANTI-CLOCKWISE.
- Page 8 Manrose Manufacturing Contact Information Unit 23, 53 Suttons Park Avenue Website: www.manrose.co.uk Earley email: sales@manrose.com Reading Sales hotline: 01753 691399 RG6 1AZ Technical hotline: 01753 876941 EU Authorised Representative: Manrose Bedrijvenweg 17 7442 CX Nijverdal Nederland authorisedrep@manrose.nl 496934 A 0621...
