Manrose FAN2303 Manual

External Wall Fans
To ensure correct function and safety, please read all instructions before using the product and keep all instructions for future reference.
SPECIFICATIONS
Duct
Fan Type
(mm)
Axial
Centrifugal 190
150
Centrifugal 220
* Use Centrifugal 190 HIGH fan speed data provided for fan FAN2301
** Use Centrifugal 220 HIGH fan speed data provided for fan FAN2302
DIMENSIONS
A B C
305 110 369
TECHNICAL
Supply Max. Operating Temp
220-240V AC, 50Hz
FAN TIMER SELECTION
Please use the FAN2444 fan timer model shown
Installation Instructions
enquiry@manrose.co.nz | www.manrose.co.nz
Thank you for purchasing this quality external wall fan.
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fi re, electrical shock and personal injury.
Max.
Fan Speed Fan Watts
(W)
18
High* 65
Medium 57
Low 55
High** 96
Medium 69
Low 60
A
B
C
IP Rating
40°C IPX3
Specifi cations are subject to change without notice
Description
Standard Models
Axial
Centrifugal - 190mm Scroll Diameter
Centrifugal - 220mm Scroll Diameter
3 Speed Models
Centrifugal - 190mm Scroll Diameter
Centrifugal - 220mm Scroll Diameter
Wall fans are designed to move air effi ciently over long distances in residential and
light commercial applications where high performance and low noise is required.
Max.
Free Air Fan Performance
Fan Pressure
(Pa)
(l/s)
91 105
280 113
250 94
200 77
380 136
340 113
280 94
Do not use old model FAN2444 (with resistor) or FAN0372 fan timers
Specific
Fan Power
(W/l/s)
(m 3 /hr)
380 0.17
408 0.58
340 0.61
277 0.71
493 0.71
408 0.61
340 0.64
Compliance: AS/NZS60335-2.80:2016
Distributed by Simx Limited
Order Code
FAN2303
FAN2301
FAN2302
FAN2316
FAN2317
Sound
dB(A)
38
60
56
46
61
56
50
Page 1
