Omcan FA12 Instruction Manual page 8

Parts Breakdown
Model FA12
21720
Description
Gear box assembly
Screw (with washer) M4*12
CJ2 padding block
Initiation capacitor 75uf 250VAC
New stainless steel decoration
Nut M4
Bottom plate
Wire fixer
Screw M4*10
Operation capacitor 16uf 450VAC
Hexagon screw M8*24
Spring gasket 8
Gasket 8*1
Double sealed bearing 6203-2RZ
Seal ring B24×40×7
Screw M4*10
Spring gasket 4
Flat spacer 4
Position Description
1 FP0 wire presser
2 Turn switch
3 Sunken screw M4*10
4 Screw M4*12
5 Switch panel
6 Switch
7 Motor base
8 Power wire protection ring
9 Power wire
10 Nickel hexagon screw M4×8
11 Chromed back cover
12 Motor assembly
13 Gang bevel gear
14 Stainless steel gasket 14×0
15 High-temperature resisted gasket
16 Small POM gasket
17 Small bevel gear
18 Pin 3×16
8
Position Description
19 Big bevel gear
20 Pin 3×12
21 Warding ring 40
22 Flat shaft
23 Flat shaft
24 Stuff hopper
25 Gear box cover
26 Short handle
27 Flat spacer 5×10×1
28 Nickel hexagon screw M5×25
29 Meat chopping cylinder
30 Aluminum screw
31 Big chopping blade
32 Steel-made big screen plate
33 Steel-made big screen plate
34 Screw cap
35
36
Position
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
