Parts Breakdown
Model FA22
21634
Description
Screw cap
Cutting plate 5
Cutting plate 8
Cutting blade
Hopper plate
Food pusher
Socket head cap screw M5×25
Spring washer 5
Washer 5
Locking knob
Stainless steel washer 22×14.2×0.8
Two fold gang bevel wheel
Stainless steel plate
Motor assembly
Back cover
Socket head cap screw M4×8
Supply cord
Supply cord back up ring
Nickel plating screw M4×6
Overcurrent protection fuse
Bolt M3×10
Switch knob
Position Description
1 Sunk self tapping screw PT4×8
2 Bolt M4×16
3 Switch keysets
4 Switch
5 Base seat
6 Washer 8
7 Spring washer 8
8 Socket head cap screw M8×25
9 Supply cord holder
10 Washer 4×0.8
11 Spring washer 4
12 Bolt M4×10
13 Socket head cap screw M4×8
14 Bolt M4×8
15 Base board
16 Nut
17 Capacitor holder 39
18 Capacitor holder 42
19 Running capacitor
20 Starting capacitor
21 Washer 4×1.2
22 Rubber underlay
10
Position Description
23 Bolt M4×12
24 Feed screw assembly
25 Feed screw terminal
26 Feed screw
Anti friction and air proof
27
washer
Transmission case cover
28
assembly
29 Transmission case cover
30 Square hole shaft
31 Seal ring B30×40×7
Both sides sealed bearing
32
6203-2RZ
33 Anti extrusion ring
34 Pin 3×11
35 Big bevel wheel
36 Pin 3×15
37 Small bevel wheel
38 Head assembly
39 Bross tube
40 Stainless steel pin
41 Head
42 Locking pin
43
44
Position
45
100
101
102
103
200
201
202
203
204
205
206
207
208
209
300
301
302
303
304
